AXIS P14 SERIES · NDAA & TAA COMPLIANT
Intelligent, Long-Range Surveillance Powered by Next-Gen AI
The AXIS P1485-LE is a robust, high-performance outdoor bullet camera engineered specifically for demanding commercial applications that require long-range detection and forensic detail. Operating on the cutting-edge AXIS ARTPEC-9 system-on-chip, this advanced camera integrates a dedicated Deep Learning Processing Unit (DLPU) to run next-generation edge analytics with supreme accuracy. From high-speed traffic monitoring to secure perimeter enforcement, its telephoto varifocal lens captures crystal-clear video across extensive areas under any light condition.
Resolution
2MP Full HD (1080p)
Optics
10.8-28.2mm Telephoto
Night Vision
80m OptimizedIR
Protection
IP66/67 & IK10 Rated
State-of-the-Art Imaging Technologies & Efficient Compression
Engineered with exceptional low-light technology, the AXIS P1485-LE features Lightfinder 2.0 and Forensic WDR to provide color accuracy and clear, high-contrast imagery even when facing extreme differences in dark and light areas. Through the incorporation of the next-gen AV1 video codec and Axis Zipstream, this system actively optimizes bandwidth and storage footprints without compromising crucial image details. It is also packed with Axis Edge Vault, a hardware-based cybersecurity platform that ensures secure key storage, secure boot, and a signed operating system.
Deep Learning Processing Unit (DLPU)
The hardware-integrated DLPU enables highly granular object classification directly at the edge. AXIS Object Analytics accurately distinguishes humans and vehicles, allowing administrators to customize trigger criteria, reduce false alarms, and streamline forensic search operations.
Long-Range OptimizedIR Illumination
OptimizedIR adapts the angle of illumination as the remote optical zoom modifies its focal length. Delivering even illumination in complete darkness up to 80 meters (262 feet) or more, this technology prevents overexposure of close-up objects while exposing distant threats.
Technical Specification Matrix
| Camera Model |
AXIS P1485-LE |
| Image Sensor |
1/2.8" progressive scan RGB CMOS |
| Lens & Focal Length |
Varifocal, 10.8–28.2 mm, F1.7–1.76, Remote Zoom & Focus, P-iris, IR corrected |
| Field of View |
Horizontal: 29.4° to 11°, Vertical: 16.5° to 6.3° |
| System on Chip |
ARTPEC-9 with Deep Learning Processing Unit (DLPU) |
| Video Compression |
AV1, H.265 (Main Profile), H.264 (Baseline/Main/High), Motion JPEG with Zipstream |
| Max Resolution & Frame Rate |
1920x1080 (2 MP) @ 50/60 fps (WDR off) or 25/30 fps (WDR on) |
| Power Supply |
PoE (IEEE 802.3af/at Type 1 Class 3), Max 12.95 W; or 10–28 V DC input, Max 12.95 W |
| Casing Rating |
IP66/67, NEMA 4X, and IK10 impact-resistant aluminum and polycarbonate casing |
| Cybersecurity |
Axis Edge Vault, FIPS 140-3 Level 3 certified secure key storage, Signed OS, Secure Boot |
Is the AXIS P1485-LE compliant with government security procurement standards?
Yes. The AXIS P1485-LE is fully NDAA (National Defense Authorization Act) and TAA (Trade Agreements Act) compliant, making it highly eligible and secure for federal, government, and commercial mission-critical infrastructure deployments.
What are the key benefits of the ARTPEC-9 system-on-chip with AV1?
The ARTPEC-9 SoC accelerates deep learning algorithms directly on the device. By incorporating the license-free AV1 codec alongside Axis Zipstream, the camera dramatically lowers bitrate, bandwidth overhead, and storage costs while retaining high-fidelity visual evidence.
How does the telephoto lens affect target identification at long distances?
With a focal length range of 10.8mm to 28.2mm, this telephoto lens offers narrower fields of view (down to 11° horizontal) that pull distant subjects closer. This optical magnification allows for high-pixel-density captures at great ranges, which is ideal for license plate recognition and vehicle verification.
Can this camera withstand harsh outdoor environments?
Absolutely. It features an IP66, IP67, and NEMA 4X weather-proof rating to protect against water, dust, and corrosion. Additionally, its IK10-rated vandal-resistant casing resists physical tampering, and it starts up reliably in temperatures as low as -40 °C (-40 °F).
