AXIS M42 SERIES · NDAA & TAA COMPLIANT
Discreet Ultra-HD Monitoring with Advanced Varifocal Control
The AXIS M4228-LVE sets a premium standard for discreet, ultra-high-definition surveillance within demanding outdoor environments and modern commercial structures. Delivering native 4K UHD resolution at up to 30 frames per second, this compact dome network camera provides forensic-level imaging detailing wide areas effortlessly. Outfitted with an adjustable varifocal lens and a low-profile chassis designed to blend seamlessly into architectural features, it serves as an excellent security anchor for retail spaces, corporate entries, and perimeter zones.
Optics
Varifocal / Remote Zoom
Night Vision
OptimizedIR 20m (65ft)
Protection
IP66 / IK08 Weatherproof
Advanced Hardware Intelligence and Cybersecurity Compliance
Built upon an advanced System on Chip (SoC), the AXIS M4228-LVE incorporates a dedicated Deep Learning Processing Unit (DLPU) that drives sophisticated edge analytics without sacrificing processing bandwidth. Intelligent functionalities like AXIS Object Analytics classify humans and vehicle types in real time, dramatically mitigating false-positive triggers. To defend vital network architecture, the integrated Axis Edge Vault platform implements hardware-based cryptographic operations including FIPS 140-3 Level 3 certified secure key storage, secure boot sequences, and signed firmware protocols.
Edge-Based Deep Learning Analytics
By running AI models natively on the edge via its DLPU, the camera processes data instantly to distinguish between humans, cars, trucks, and cyclists. This reduces dependence on centralized server infrastructure while speeding up forensic search workflows within your Video Management Software (VMS).
Lightfinder and Forensic WDR Integration
AXIS Forensic WDR balances intense, high-contrast lighting to reveal details in both extreme highlight and deep shadow regions simultaneously. For extreme low-light environments, Lightfinder technology extracts full-color structural clarity down to negligible lux levels prior to shifting into infrared mode.
Technical Specification Matrix
| Camera Model |
AXIS M4228-LVE |
| Image Sensor |
1/2.8" Progressive Scan RGB CMOS |
| Maximum Resolution |
3840 x 2160 (8 Megapixel / 4K Ultra HD) |
| Frame Rate |
Up to 25/30 fps with H.264, H.265, and Motion JPEG |
| Lens Properties |
Varifocal, 3 to 6 mm, F1.4 to F2.1, Remote Zoom & Focus |
| Field of View |
Horizontal: 100° to 49°, Vertical: 53° to 27° |
| Video Compression |
H.264 (Main and High), H.265 (HEVC), Axis Zipstream Technology |
| Cybersecurity Hardware |
Axis Edge Vault, Secure Keystore, Secure Boot, Signed OS |
| Environmental Ratings |
IP66 Weatherproof, IK08 Vandal-Resistant, NEMA 4X |
| Power Over Ethernet |
PoE IEEE 802.3af/at Type 1 Class 3 (Maximum 11.9W) |
Does the AXIS M4228-LVE require an external server for AI object analytics?
No. Thanks to its integrated Deep Learning Processing Unit (DLPU), all classification, tracking, and object analytics are completed on-board the edge hardware, saving considerable server infrastructure cost and reducing network bandwidth overhead.
Is this model fully compliant with government security purchasing requirements?
Yes. The AXIS M4228-LVE is both NDAA and TAA compliant, making it structurally qualified for installation within government contracts, defense frameworks, and highly regulated institutional network environments.
What is the primary operational advantage of a remote zoom varifocal lens?
The varifocal lens enables installers to adjust the field of view over the network. Once physical installation is complete, the zoom levels and precise focal points can be configured digitally through the software interface, eliminating manual camera tracking on ladders.
How does Axis Zipstream technology optimize storage configurations?
Axis Zipstream examines the video matrix in real time to isolate moving parts, faces, and critical details. It applies high compression exclusively to static background areas, reducing total network storage and system bandwidth needs by 50% or more without degrading essential forensic clarity.
