TP-Link Archer MX700 5G AX6000 Wi-Fi 6 Router
Fast 5G Fixed Wireless Internet with AX6000 Wi-Fi 6
The TP-Link Archer MX700 combines a sub-6 GHz 5G modem with AX6000 dual-band Wi-Fi 6 in a single home router. Insert a SIM card from any compatible Australian carrier and replace your fixed-line broadband — or use it as a primary internet connection where NBN is unavailable, unreliable, or simply not fast enough.
Description
5G fixed wireless access is rapidly expanding across Australia, and the Archer MX700 is built to take full advantage of it. Supporting sub-6 GHz 5G with download speeds of up to 3.6 Gbps on compatible networks, it delivers a genuine fixed broadband alternative for homes, home offices, and small businesses in 5G coverage areas.
The integrated AX6000 Wi-Fi 6 radio distributes that 5G connection across your home at combined wireless speeds of up to 6000 Mbps — 2.4 GHz and 5 GHz — with OFDMA and MU-MIMO ensuring efficient performance across multiple devices simultaneously. A 2.5 Gbps LAN port provides a wired connection for NAS devices, gaming PCs, or smart TVs that demand the fastest possible throughput.
The Archer MX700 is SIM-unlocked and compatible with major Australian 5G carriers. Four external antennas with 4G/5G signal optimisation help maintain a strong connection even in areas with moderate signal strength. Setup and management are handled through the TP-Link Tether app or a full web interface.
Key Features
-
5G Sub-6 GHz — Download speeds up to 3.6 Gbps on compatible 5G networks
-
AX6000 Wi-Fi 6 — Dual-band: 2.4 GHz 1148 Mbps + 5 GHz 4804 Mbps combined
-
SIM Unlocked — Compatible with all major Australian 5G carriers (Telstra, Optus, Vodafone)
-
2.5 Gbps LAN Port — Multi-gigabit wired connection for NAS, gaming PCs, and smart TVs
-
4× Gigabit LAN Ports — Wired connectivity for multiple devices simultaneously
-
OFDMA & MU-MIMO — Efficient multi-device Wi-Fi performance across busy households
-
4× External Antennas — Optimised for 5G/4G signal reception and Wi-Fi coverage
-
4G LTE Fallback — Automatically falls back to 4G LTE when 5G is unavailable
-
WPA3 Security — Latest wireless encryption standard
-
Tether App & Web UI — Easy setup and remote management via iOS or Android
Use Cases
- Homes and home offices in 5G coverage areas replacing or supplementing NBN
- Rural and regional properties where NBN speeds are insufficient or unavailable
- Small businesses requiring fast, reliable internet without fixed-line infrastructure
- Temporary offices, construction sites, and pop-up locations needing fast broadband
- Backup internet connection during NBN or fixed-line outages
- Properties awaiting NBN connection requiring an immediate broadband solution
Specifications
| Specification |
Detail |
| 5G Standard |
5G NR Sub-6 GHz (NSA/SA) |
| 5G Download Speed |
Up to 3.6 Gbps |
| 4G Fallback |
Yes (LTE Cat20, up to 2 Gbps) |
| SIM Type |
Nano SIM |
| SIM Lock |
Unlocked (all AU carriers) |
| Wi-Fi Standard |
IEEE 802.11ax/ac/n/g/b/a (Wi-Fi 6) |
| Wi-Fi Speed |
AX6000: 2.4 GHz 1148 Mbps + 5 GHz 4804 Mbps |
| Wi-Fi Bands |
Dual-Band (2.4 GHz / 5 GHz) |
| OFDMA |
Yes (UL/DL) |
| MU-MIMO |
4×4 (2.4 GHz) / 4×4 (5 GHz) |
| 2.5G LAN Port |
1× 2.5 Gbps LAN |
| Gigabit LAN Ports |
4× Gigabit LAN |
| USB Port |
1× USB 3.0 |
| Antennas |
4× external (5G/4G + Wi-Fi combined) |
| Processor |
Quad-Core 1.5 GHz |
| Memory |
1 GB RAM / 512 MB Flash |
| Security |
WPA3, WPA2, SPI Firewall |
| Management |
TP-Link Tether app (iOS & Android), web UI |
| Power |
12V/4A |
| Operating Temperature |
0°C – 40°C |
| Certifications |
RCM (Australia/NZ), ACMA |
| Package Contents |
1× Archer MX700 router, 4× antennas, 1× power adapter, quick start guide |
Recommended Accessories
-
Prepaid or SIM-Only 5G Data Plan — Insert a Telstra, Optus, or Vodafone nano SIM with a 5G data plan to get online immediately
-
TP-Link TL-SG108-M2 — Multi-Gigabit switch to extend 2.5G wired connectivity across your network
-
Cat6A Ethernet Cable — Required for full 2.5 Gbps speeds on the wired LAN port
-
External 5G Antenna (TS-9 or SMA) — For installations in low-coverage areas requiring improved 5G signal reception
-
UPS / Battery Backup — Maintain internet connectivity during power outages for critical home office or business use
Downloads
Frequently Asked Questions
- Which Australian 5G carriers are compatible with the Archer MX700?
- The Archer MX700 is SIM-unlocked and designed for use with Australian 5G carriers including Telstra, Optus, and Vodafone. Compatibility depends on the 5G frequency bands (n78, n28, etc.) supported by your carrier in your area. Check the TP-Link AU spec page for the full band list and verify with your carrier before purchase.
- Can the Archer MX700 be used as a replacement for NBN?
- Yes, in areas with strong 5G coverage. The Archer MX700 is designed as a fixed wireless broadband solution and can fully replace an NBN connection for households and small businesses with access to a reliable 5G signal. Actual speeds depend on carrier network conditions, signal strength, and data plan.
- Does the Archer MX700 fall back to 4G if 5G is unavailable?
- Yes. The Archer MX700 automatically falls back to 4G LTE (up to LTE Cat20, 2 Gbps) when a 5G signal is not available, ensuring continuous connectivity without manual intervention.
- Can I connect an external antenna to improve 5G signal?
- The Archer MX700 uses four external antennas optimised for 5G and 4G reception. For installations in very low-coverage areas, check whether the router supports external antenna port connections (TS-9 or SMA) on the live TP-Link AU spec page, as this varies by hardware revision.
- Does the Archer MX700 support EasyMesh for whole-home Wi-Fi?
- Check the latest TP-Link AU product page for EasyMesh compatibility status on this model. If EasyMesh is not supported, TP-Link range extenders can still be used in standard repeater mode to extend Wi-Fi coverage from the Archer MX700.
