Dahua CAT5e RJ45 Network Plug (100pcs/Pack)
Unshielded CAT5E RJ-45 connector.
Designed with a through hole for cables to be fed through.
Built with trident brass sheet and 15U" gold plating.
Lifespan of 750 cycles.
Downloads
PFM976-531_datasheet_20220606
Dahua UTP CAT6 15U" Pass Through RJ45 Connector
Unshielded CAT6 RJ-45 connector.
Designed with a through hole for cables to be fed through.
Built with trident brass sheet and 15U" gold plating.
Lifespan of 750 cycles.
Downloads
PFM976-631_datasheet_20220606
Dahua 4MP 25x Starlight IR WizSense Network PTZ Camera DH-SD4A425DB-HNY
1/2.8" 4Megapixel STARVIS™ CMOS.
25x optical zoom.
Starlight technology.
Max. 25/30fps@4MP.
IR distance up to 100m.
Auto-tracking.
Perimeter protection.
Face detection.
SMD 3.0.
IP66.
Specifications
MEGAPIXELS
4MP
CAMERA STYLE
PTZ
COLOUR
White
LENS TYPE
Motorized
TECHNOLOGY
PTZ SERIES
POE
POE+
Downloads
SD4A425DB-HNY_S0 DatasheetInstallation Guide_V1.0.0_(SD4A)Network Speed Dome & PTZ Camera Installation Manual_V1.0.1Dahua Network Speed Dome and PTZ Camera Web 5.0_User's Manual_V1.0.0SD4A425DB-HNY_DIMENSIONS
Dahua 64 Channel AI NVR, 2U, 8 x HDD Bay, No PoE Port, WizSense Network Video Recorder, DHI-NVR5864-AI/ANZ
This 64 Channel WizSense AI NVR comes with 8 Hard Disk Bay, 0 x PoE ports. Suitable for warehouse, corporate office and more.
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format
32-channel 1080p self-adaptive decoding capability
Support Raid0/1/5/6/10
Max. 384 Mbps incoming/recording/outgoing bandwidth
AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting
Security baseline 2.3
Specifications
Number of Channels
64 Channel
Number of PoE Ports
0 x PoE Ports
Number of Hard Disk Bay
8 x Hard Disk Bay
Technology
WizSense AI Series
Network Bandwidth
AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
System
Main Processor
Industrial-grade processor
Operating System
Embedded Linux
Operating Interface
Web, Local GUI
AI
AI by Recorder
Face detection; face recognition; perimeter protection; SMD Plus
AI by Camera
Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map
Perimeter Protection
Perimeter Performance AI by Recorder (Number of Channels)
4 channels, 10 IVS rules for each channel
Perimeter Performance of AI by Camera (Number of Channels)
16 channels
Face Detection
Face Attributes
Gender; age group; glasses; expressions; face mask; beard
Face Detection Performance of AI by Recorder (Number of Channels)
2 channels (up to 12 face images/s each channel)
Face Detection Performance of AI by Camera (Number of Channels)
16 channels
Face Recognition
Face Database Capacity
Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
Face Recognition Performance of AI by Recorder (Number of Channels)
1. 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s2. 2-channe FD (by recorder) + FR (by recorder), video stream: 12 face images/s
Face Recognition Performance of AI by Camera (Number of Channels)
16 channels
SMD Plus
SMD Plus by Recorder
8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change
SMD Plus by Camera
16 channels
Video Metadata
Metadata Performance of AI by Camera (Number of Channels)
8 channels
Human Attributes
Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella
Motor Vehicle Attributes
License plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location.
Non-motor Vehicle Attributes
Vehicle model, vehicle color, number of persons, helmet.
Vehicle License Plate Comparison
ANPR by Camera (Number of Channels)
8 channels
License Plate Database Capacity
1. Create up to 20,000 plate numbers.2. Blocklist and allowlist
Audio and Video
Access Channel
64
Network Bandwidth
AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoingAI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
Resolution
32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF
Decoding Capability
AI disabled: 2-channel 32 MP@20 fps; 2-channel 24 MP@20 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fpsAI enabled: 1-channel 32 MP@20 fps; 1-channel 24 MP@20 fps; 2-channel 16 MP@30 fps; 4-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 8-channel 5 MP@30 fps; 12-channel 4 MP@30 fps; 24-channel 1080p@30 fps
Video Output
2-channel VGA, 2-channel HDMI video output.Heterogeneous video source output for HDMI1 and HDMI2Simultaneous video source output for VGA1 and HDMI1Simultaneous video source output for VGA2 and HDMI2Supports 4K display
Multi-screen Display
Main screen: 1/4/8/9/16/25/36/64Sub screen: 1/4/8/9/16
Third-party Camera Access
ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Samsung
Compression Standard
Video Compression
Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
Audio Compression
G.711a; G.711u; PCM; G726
Network
Network Protocol
HTTP; HTTPS; TCP/IP; IPv4/IPv6; RTSP; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration
Mobile Phone Access
iOS; Android
Interoperability
ONVIF 21.12(Profile T; Profile S; Profile G); CGI; SDK
Browser
ChromeIE 9 or laterFirefox
Network Mode
Multi-address mode, load balance, fault tolerance and other network port binding modes
Recording Playback
Multi-channel Playback
Up to 16 channels
Record Mode
General, motion detection; intelligent; alarm; POS
Backup Method
USB device and network
Playback Mode
Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection)
Storage
Disk Group
Yes
RAID
RAID 0/1/5/6/10
Alarm
General Alarm
Motion detection; privacy masking; local alarm
Anomaly Alarm
Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan; cybersecurity exception
Intelligent Alarm
Face detection; perimeter protection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map
Alarm Linkage
Record; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; audio; buzzer; log, preset; email
Port
Audio Input
1-channel RCA
Audio Output
2-channel RCA
Alarm Input
16 channels
Alarm Output
8 channels (1-channel 12 V 1 A output)
HDD Interface
8 SATA ports, up to 16 TB.The maximum HDD capacity varies with environment temperature.
eSATA
1
RS-232
1
RS-485
2 (1 port for half-duplex serial communication, 1 port for full-duplex serial communication)
USB
4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports)
HDMI
2
VGA
2
Network Port
2(10/100/1000 Mbps Ethernet port, RJ-45)
General
Power Supply
100–240 VAC, 50-60 Hz
Power Consumption
Total output of NVR is ≤ 13 W (without HDD)
Net Weight
6.4 kg (14.11 lb)
Gross Weight
9.01 kg (19.86 lb)
Product Dimensions
439.9 mm × 457.9 mm x 89.0 mm (17.32" × 18.03" × 3.50") (W ×D × H)
Packaging Dimensions
570.0 mm × 570.0 mm x 226.0 mm (22.44" × 22.44" × 8.90") (W ×D × H)
Operating Temperature
–10 °C to +55 °C (14 °F to +131 °F)
Storage Temperature
–20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity
10%–93% (RH)
Installation
Rack or desktop
Certifications
FCC: 47 CFR FCC Part15, SubpartB, Class ACE-EMC: EN 55032: 2015+A1: 2020; EN IEC 61000-3-2: 2019+A1: 2021; EN 61000-3-3: 2013+A1: 2019+A2: 2021; EN 55035: 2017+A11: 2020; EN 50130-4: 2011+A1: 2014CE-LVD: EN 62368-1: 2014
Downloads
Datasheet
Hikvision DS-2CD2165G0-I 6 MP Powered-by-DarkFighter Fixed 4mm Dome Network Camera
High quality imaging with 6 MP resolution
Excellent low-light performance via powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
-S: audio and alarm interface available
Water and dust resistant (IP67) and vandal proof (IK10)
Robust structure design with full metal materials.
Hikvision AcuSense Turret, 4MP DS-2CD2346G2-ISU-SL-4, IP67, IR, Built-in Mic, Speaker, Strobe Light, 4mm (2346)
DS-2CD2346G2-ISU/SL(4mm)
High quality imaging with 4 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Clear imaging against strong backlight due to 120 dB true WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle targets classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Provides real-time security via built-in two-way audio
Water and dust resistant (IP67)
Downloads
Datasheet
Hikvision AcuSense Turret DS-2CD2346G2-ISU-SL-2, 4MP, IP67, IR, Built-in Mic, Speaker, Strobe Light, 2.8mm (2346)
DS-2CD2346G2-ISU/SL(2.8mm)
High quality imaging with 4 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Clear imaging against strong backlight due to 120 dB true WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle targets classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Provides real-time security via built-in two-way audio
Water and dust resistant (IP67)
Downloads
Datasheet
Hikvision 6 MP AcuSense Motorised Varifocal Dome Network Camera DS-2CD2766G2-IZS
High quality imaging with 6 MP resolution
Motorized varifocal lens for easy installation and monitoring
Excellent low-light performance with powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Audio and alarm interface available
Water and dust resistant (IP66) and vandal proof (IK10)
Downloads
Datasheet
Hikvision 4K Powered-by-DarkFighter Varifocal Bullet Network Camera DS-2CD2685G1-IZS
High quality imaging with 8 MP resolution
Excellent low-light performance via powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Water and dust resistant (IP67) and vandal proof (IK10)
Motorized vari-focal lens for easy installation and monitoring
Robust structure design with full metal materials.
Downloads
Datasheet
Hikvision DS-2CD2386G2-ISU/SL AcuSense Gen 2, Turret, 8MP, 4K, 2.8mm, AcuSense, Turret Network Camer
Empowered by deep learning algorithms, Hikvision AcuSense technology brings human or vehicle target classification alarms to front- and back-end devices. The system can greatly reduce false alarms generated by targets other than humans or vehicles, vastly improving alarm efficiency and effectiveness.
Features
High quality imaging with 8 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Clear imaging against strong back light due to 120 dB true WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle targets classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
Water and dust resistant (IP67)
Downloads
DS-2CD2386G2-ISU/SL Datasheet
Hikvision 6 MP AcuSense Strobe Light and Audible Warning Fixed Turret Network Camera - DS-2CD2366G2-ISU/SL Available in 2.8mm and 4mm.
The Hikvision DS-2CD2366G2-ISU/SL 6MP AcuSense Turret offers high quality imaging with 6 MP resolution and excellent low-light performance thanks to powered-by-DarkFighter technology. With 120 dB true WDR technology and efficient H.265+ compression, this camera provides clear imaging against strong back light. It also features deep learning-based human and vehicle target classification, and active strobe light and audio alarms to deter intruders. The built-in two-way audio allows for real-time security, and the camera is water and dust resistant with an IP67 rating.
Features
High quality imaging with 6 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Clear imaging against strong back light due to 120 dB true WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle targets classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
Water and dust resistant (IP67)
Downloads
DS-2CD2366G2-ISU/SL Datasheet
Hikvision ColorVu Turret DS-2CD2347G2-LU-4, 4MP, White Light, AcuSense, Mic, 4mm (2347)
High quality imaging with 4 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Built-in microphone for real-time audio security(-U)
Focus on human and vehicle targets classification based on deep learning
24/7 colorful imaging
Water and dust resistant (IP67)
Camera
Image Sensor
1/1.8" Progressive Scan CMOS
Max. Resolution
2688 × 1520
Min. Illumination
Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time
1/3 s to 1/100,000 s
Angle Adjustment
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens, 2.8, 4, and 6 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 112°, vertical FOV 61°, diagonal FOV 134°
4 mm, horizontal FOV 95°, vertical FOV 51°, diagonal FOV 115°
6 mm, horizontal FOV 58°, vertical FOV 31°, diagonal FOV 69°
Lens Mount
M16
Iris Type
Fixed
Aperture
F1.0
Depth Of Field
2.8 mm, 2.5 m to ∞
4 mm, 3.5 m to ∞
6 mm, 7.5 m to ∞
DORI
DORI
2.8 mm, D: 58 m, O: 23 m, R: 11 m, I: 2 m
4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m
6 mm, D: 115 m, O: 45 m, R: 23 m, I: 11 m
Illuminator
Supplement Light Type
White Light
Supplement Light Range
30 m
Smart Supplement Light
Yes
Video
Main Stream
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings.
Video Compression
Main stream: H.265/H.264/H.265+/H.264+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
*Third stream is supported under certain settings.
Video Bit Rate
32 Kbps to 8 Mbps
H.264 Type
Baseline Profile/Main Profile/High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR/VBR
Scalable Video Coding (SVC)
H.264 and H.265 encoding
Region Of Interest (ROI)
1 fixed region for main stream and sub-stream
Audio
Audio Compression
-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate
-U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate
-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering
-U: Yes
Network
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
Simultaneous Live View
Up to 6 channels
API
Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
User/Host
Up to 32 users. 3 user levels: administrator, operator and user
Security
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage
MicroSD/microSDHC/microSDXC card (512 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health detection are supported
Client
iVMS-4200, Hik-Connect, Hik-Central
Web Browser
Plug-in required live view: IE 10, IE 11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Parameters Switch
Yes
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch
Auto, Schedule
Wide Dynamic Range (WDR)
130 dB
SNR
≥ 52 dB
Image Enhancement
BLC, HLC, 3D DNR
Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-In Microphone
-U: Yes
Reset Key
Yes
Event
Basic Event
Motion detection (human and vehicle targets classification), video tampering alarm, exception
Smart Event
Line crossing detection, intrusion detection, region entrance detection, region exiting detection
Scene change detection
Linkage
Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email
Deep Learning Function
Face Capture
Yes
General
Power
12 VDC ± 25%, 0.55 A, max. 6.6 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE: 802.3af, Class 3, 36 V to 57 V, 0.22 A to 0.13 A, max. 7.6 W
Dimension
Ø138.3 mm × 125.2 mm (Ø5.4" × 4.9")
Package Dimension
170 mm × 170 mm × 150 mm (7" × 7" × 5.9")
Weight
Approx. 750 g (1.7 lb.)
With Package Weight
Approx. 1055 g (2.3 lb.)
Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language
33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function
Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
Approval
EMC
FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC VoC (ICES-003: Issue 6, 2016);
KC (KN 32: 2015, KN 35: 2015)
Safety
UL (UL 60950-1);
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);
LOA (IEC/EN 60950-1)
Environment
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection
IP67 (IEC 60529-2013)
Download
DS-2CD2347G2-LU Datasheet
DS-2CD2347G2-LU Quick Start GuideDS-2CD2347G2-LU User Manual
Dahua AI access ANPR 2 Megapixel Full HD WDR ANPR Camera, IR, max 40km/hr, 10-50mm Motorised lens, max 25m distance
CMOS image sensor
Video compression standards: H.265/H.264M/H.264H/H.264B/MJPEG
Integrated design, and IP67,IK10 protection grade
Specifications
MEGAPIXELS
2MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Motorized
TECHNOLOGY
License Number Plate Series
POE
POE+
Downloads
DHI-ITC237-PW6M-IRLZF1050-B DatasheetDahua Access ANPR Camera User Manual V2.0.04
Dahua 4MP IR Fixed-focal Bullet WizSense 4G Network Camera DH-IPC-HFW3441DG-AS-4G-EAU-B
4-MP 1/3'' CMOS image sensor, low luminance, and high definition image
Outputs max. 4 MP (2688 x 1520) @25/30 fps
H.265 codec, high compression rate, ultra-low bit rate
Built-in warm light/IR LED
Sound and light alarm linkage. When the alarm is triggered, the sound and light will be linked
Built in high-performance 4G Module that suits all mobile networks. Installation is no longer limited to wired networks
Built-in PIR sensor that detects human body through passive infrared which is sensitive to body temperature
Built-in 8 GB eMMC memory chip that protects key records from being lost
Abnormality detection: Motion detection, video tampering, audio detection, SD card full, SD card error, network disconnection, IP conflict and illegal access
Alarm: 1 in, 1 out; audio: 1 in, 1 out; RS485:1 (Only report the information of solar battery, such as power and battery level), Supports max. 256 G Micro SD card; built in MIC and speaker; support two-way talk
IP67 protection
Specifications
MEGAPIXELS
4MP
CAMERA STYLE
Bullet
COLOUR
White
LENS TYPE
Fixed
TECHNOLOGY
Special Series
POE
12V DC
Downloads
IPC-HFW3441DG-AS-4G-EAU-B Datasheet_20221021Dahua Bullet Network Camera_Installation Guide_V1.0.0Dahua Bullet Network Camera_Quick Start Guide_V1.0.1Dahua Network Camera Web 3.0_OperationManual_V2.1.5Dahua Network Camera Web 5.0_Operation Manual_V1.0.6
Wall Mount Bracket DH-AC-PFB605W
Material: Aluminum
Wall mount bracket
Aesthetic design
Specifications
CAMERA BRACKETS
TYPE
Wall mount
MATERIAL
Aluminum
COLOUR
White
DIMENSION
92.0mm x 121.3mm x 284.5mm (10.39'' x 3.94'' x 5.75'')
Downloads
PFB605W Datasheet 20180608
Recommend for a corporate office, two-storey home and more. This surveillance kit comes with 10 x 4MP cameras (Black) and 4TB of storage; you can save and review footage. Safely monitor and secure every second of your place.
Dahua 3x66 4MP 8ch Kit includes:
6 x 4MP 2.8mm Fixed Lens DH-IPC-HDW3466EMP-S-AUS-BLK
1 x 8ch DHI-NVR4108HS-8P-4KS2/L-4TB
DH-IPC-HDW3466EMP-S-AUS-BLKDahua Security Camera 4MP WizSense Fixed Starlight Turret, 2.8mm, Perimeter, SMD, SD Card, WDR, IR50m, Built-in Mic, IP67, POE, black
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
DHI-NVR4108HS-8P-4KS2/LDahua 8ch NVR Record Up to 8MP, 8 Port PoE, HDMI (4K), Smart 2.0, P2P (without HDD)
New 4.0 user interface, Security baseline 2.1
H.264, H.265, Smart H.264+, and Smart H.265+. H.265 auto switch
Max. decoding capability: 8x1080p@30 fps. Supports adaptive decoding
Supports mainstream cameras of ONVIF and RTSP protocols
P2P remote surveillance, video play on mobile device
VGA/HDMI simultaneous video output, maximum resolution of HDMI is 4K
AI by Camera: Face detection, perimeter protection, IVS, people counting, heat map, and SMD
Supports remote configuration and management of IPC, such as set ting parameters, getting information, and upgrading IPC of the same model in batches
Recommend for a small office, one-storey home and convenience store. This surveillance kit comes with 4 x 4MP cameras (Black) and 2TB of storage; you can save and review footage. Safely monitor and secure every second of your place.
Dahua 3x66 4MP 4ch Kit includes:
4 x 4MP 2.8mm Fixed Lens DH-IPC-HDW3466EMP-S-AUS-BLK
1 x 4ch DHI-NVR4104HS-P-AI/ANZ-2TB
DH-IPC-HDW3466EMP-S-AUS-BLKDahua Security Camera 4MP WizSense Fixed Starlight Turret, 2.8mm, Perimeter, SMD, SD Card, WDR, IR50m, Built-in Mic, IP67, POE, black
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
DHI-NVR4104HS-P-AI/ANZDahua Compact NVR, DHI-NVR4104HS-P-AI/ANZ, 4 Channels, 1U, 1 HDD Bay, Record Up to 16MP, 4 PoE, HDMI( 4K), SMD 4.0, P2P, WizSense Network Video Recorder
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 80 Mbps.
Max. decoding capability: 16 x 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
Recommend for a corporate office, two-storey home and more. This surveillance kit comes with 10 x 4MP cameras (white) and 3TB of storage; you can save and review footage. Safely monitor and secure every second of your place.
Dahua 3x66 4MP 16ch Kit includes:
10 x 4MP 2.8mm Fixed Lens DH-IPC-HDW3466EMP-S-AUS
1 x 16ch DHI-NVR4216-16P-AI/ANZ
DH-IPC-HDW3466EMP-S-AUSDahua 4MP WizSense Fixed Starlight Turret, 2.8mm, Perimeter, SMD, SD Card, WDR, IR50m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
DHI-NVR4216-16P-AI/ANZDahua 16ch NVR Record Up to 16MP, 16 Port PoE, HDMI(4K), Smart 2.0, P2P (without HDD), Support 2 HDD DHI-NVR4216-16P-AI/ANZ
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).
Max. decoding capability: 16 x 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
Recommend for a corporate office, two-storey home and more. This surveillance kit comes with 10 x 4MP cameras (white) and 4TB of storage; you can save and review footage. Safely monitor and secure every second of your place.
Dahua 3x66 4MP 8ch Kit includes:
6 x 4MP 2.8mm Fixed Lens DH-IPC-HDW3466EMP-S-AUS
1 x 8ch DHI-NVR4108HS-8P-4KS2/L-4TB
DH-IPC-HDW3466EMP-S-AUSDahua 4MP WizSense Fixed Starlight Turret, 2.8mm, Perimeter, SMD, SD Card, WDR, IR50m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
DHI-NVR4108HS-8P-4KS2/LDahua 8ch NVR Record Up to 8MP, 8 Port PoE, HDMI (4K), Smart 2.0, P2P (without HDD)
New 4.0 user interface, Security baseline 2.1
H.264, H.265, Smart H.264+, and Smart H.265+. H.265 auto switch
Max. decoding capability: 8x1080p@30 fps. Supports adaptive decoding
Supports mainstream cameras of ONVIF and RTSP protocols
P2P remote surveillance, video play on mobile device
VGA/HDMI simultaneous video output, maximum resolution of HDMI is 4K
AI by Camera: Face detection, perimeter protection, IVS, people counting, heat map, and SMD
Supports remote configuration and management of IPC, such as set ting parameters, getting information, and upgrading IPC of the same model in batches
Recommend for a corporate office, two-storey home and more. This surveillance kit comes with 10 x 4MP cameras (white) and 4TB of storage; you can save and review footage. Safely monitor and secure every second of your place.
Dahua 3x66 4MP 8ch Kit includes:
6 x 4MP 2.7-13.5mm Motorised Lens DH-IPC-HDW3466TP-ZS-AUS
1 x 8ch DHI-NVR4108HS-8P-4KS2/L-4TB
DH-IPC-HDW3466TP-ZS-AUSDahua Security Camera 4MP WizSense Motorised Starlight Turret, 2.7–13.5 mm, Perimeter, SMD, SD Card, WDR, IR40m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion , tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
DHI-NVR4108HS-8P-4KS2/LDahua 8ch NVR Record Up to 8MP, 8 Port PoE, HDMI (4K), Smart 2.0, P2P (without HDD)
New 4.0 user interface, Security baseline 2.1
H.264, H.265, Smart H.264+, and Smart H.265+. H.265 auto switch
Max. decoding capability: 8x1080p@30 fps. Supports adaptive decoding
Supports mainstream cameras of ONVIF and RTSP protocols
P2P remote surveillance, video play on mobile device
VGA/HDMI simultaneous video output, maximum resolution of HDMI is 4K
AI by Camera: Face detection, perimeter protection, IVS, people counting, heat map, and SMD
Supports remote configuration and management of IPC, such as set ting parameters, getting information, and upgrading IPC of the same model in batches
Recommend for a corporate office, two-storey home. This surveillance kit comes with 10 x 4MP motorised cameras (white) and 6TB of storage. You can record and review footage from the past from continuous recordings. Plus, you can safely monitor and receive notifications remotely from anywhere in the world with the Dahua DMSS app or SmartPSS.
Dahua 3x66 4MP 16 Channel Kit includes:
10 x 4MP 2.7-13.5mm Motorised Lens DH-IPC-HDW3466TP-ZS-AUS
1 x 16ch DHI-NVR4216-16P-AI/ANZ-6TB
DH-IPC-HDW3466TP-ZS-AUSDahua Security Camera 4MP WizSense Motorised Starlight Turret, 2.7–13.5 mm, Perimeter, SMD, SD Card, WDR, IR40m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 40 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion , tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
DHI-NVR4216-16P-AI/ANZDahua 16ch NVR Record Up to 16MP, 16 Port PoE, HDMI(4K), Smart 2.0, P2P (without HDD), Support 2 HDD DHI-NVR4216-16P-AI/ANZ
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).
Max. decoding capability: 16 x 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
Recommend for a small office, one-storey home and convenience store. This surveillance kit comes with 4 x 4MP cameras (white) and 2TB of storage; you can save and review footage. Safely monitor and secure every second of your place.
Dahua 3x66 4MP 4ch Kit includes:
4 x 4MP 2.8mm Fixed Lens DH-IPC-HDW3466EMP-S-AUS
1 x 4ch DHI-NVR4104HS-P-AI/ANZ-2TB
DH-IPC-HDW3466EMP-S-AUSDahua 4MP WizSense Fixed Starlight Turret, 2.8mm, Perimeter, SMD, SD Card, WDR, IR50m, Built-in Mic, IP67, POE
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
DHI-NVR4104HS-P-AI/ANZDahua Compact NVR, DHI-NVR4104HS-P-AI/ANZ, 4 Channels, 1U, 1 HDD Bay, Record Up to 16MP, 4 PoE, HDMI( 4K), SMD 4.0, P2P, WizSense Network Video Recorder
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 80 Mbps.
Max. decoding capability: 16 x 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
Recommend for a corporate office, two-storey home and more. This surveillance kit comes with 10 x 4MP cameras (white) and 6TB of storage; you can save and review footage. Safely monitor and secure every second of your place.
Dahua 3x66 4MP 16ch Kit includes:
10 x 4MP 2.8mm Fixed Lens DH-IPC-HDW3466EMP-S-AUS-BLK
1 x 16ch DHI-NVR4216-16P-AI/ANZ-6TB
DH-IPC-HDW3466EMP-S-AUS-BLKDahua Security Camera 4MP WizSense Fixed Starlight Turret, 2.8mm, Perimeter, SMD, SD Card, WDR, IR50m, Built-in Mic, IP67, POE, black
4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
Outputs max. 4 MP (2688 x 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, max. IR distance: 50 m.
ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Max. 256 G Micro SD card. built-in Mic.
12 VDC/PoE power supply facilitates installation.
IP67 protection.
SMD 4.0, AI SSA.
DHI-NVR4216-16P-AI/ANZDahua 16ch NVR Record Up to 16MP, 16 Port PoE, HDMI(4K), Smart 2.0, P2P (without HDD), Support 2 HDD DHI-NVR4216-16P-AI/ANZ
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).
Max. decoding capability: 16 x 1080p@30 fps. Supports adaptive decoding.
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
Connected to the third-party network cameras.
Security baseline 2.3.
Hikvision In-Ceiling Bracket PTZ (4A220/4A225/4A425) - DS-1671ZJ-SD11
In-Ceiling Mount for 4-inch PTZ Camera
Steel & Plastic
Hikvision White
Parameters
Weight
Approx. 610 g (1.34 lb.)
Appearance
Hikvision White
Material
Steel
Dimension
233.3 mm × 233.3 mm × 85 mm (9.19" × 9.19" × 3.35")
Cable Hole
Ø212 mm (8.3")
Description
In-Ceiling Mounting Bracket for 4-inch PTZ Camera
Download
Quick Start Guide
Hikvision Bracket Parapet Mount For PTZ - DS-1660ZJ
Parapet Wall Mount
Aluminum Alloy & Steel
Hikvision White
Parameters
Weight
2900g
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
180×950×800 mm
Range Of Application
Parapet Wall Mount Bracket
Description
Parapet Wall Mount Bracket
Download
Quick Start Guide
Hikvision PTZ Mini Wall Mount (4A220/4A225/4A425) - DS-1605ZJ
Wall Mounting Bracket for 4-inch PTZ Camera
Aluminum Alloy
Hikvision White
Parameters
Weight
Approx. 1060 g (2.34 lb.)
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
314.4 mm × 183.5 mm × 171.7 mm (12.38" × 7.22" × 6.76")
Description
Wall Mounting Bracket for 4-inch PTZ Camera
Download
Quick Start Guide
Hikvision PTZ Vertical Pole Mount Bracket With Junction Box - DS-1604ZJ-BOX-POLE
Vertical Pole Mount for Speed Dome
Aluminum Alloy & Steel
Platinum Gray
Parameters
Weight
5.7 kg (12.57 lb.)
Appearance
Hikvision White
Material
Aluminum Alloy and Steel
Dimension
456.5 mm × 314 mm × 194.9 mm (17.97" × 12.36" × 7.67")
Description
Vertical Pole Mount for Speed Dome
Download
Quick Start Guide
Hikvision PTZ Wall Mount Box - DS-1604ZJ-BOX
Wall mounting bracket with the junction box
Aluminum alloy material with surface spray treatment
Supports bottom outlet and back outlet
The hook for safety rope facilitates speed dome’s installation
Parameters
Weight
2.15 Kg (4.74 lb.)
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
395.5 mm × 281.2 mm × 170.7 mm (15.6" × 11.07" × 6.72")
Description
Wall Mounting Bracket for Speed Dome
DownloadQuick Start Guide
Hikvision PTZ Wall Mount - DS-1604ZJ
Wall mounting bracket with the junction box
Aluminum alloy material with surface spray treatment
Junction box supports bottom outlet and back outlet
The hook for safety rope facilitates speed dome’s installation
Parameters
Weight
2150 g (4.7 lb.)
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
355.5 mm × 255.3 mm × 170.7 mm (14" × 10" × 6.7")
Description
Wall Mounting Bracket for Speed Dome
DownloadQuick Start Guide
Hikvision Vertical PTZ Pole Mount with Bracket DS-1602ZJ-Pole
Vertical Pole Mount Bracket
Aluminum Alloy & Steel
Hikvision White
Parameters
Weight
2040g
Appearance
Hikvision white
Material
Aluminum & Steel
Dimension
117×194×451.3mm
Feature
Suitable for speed dome pendent mounting
Description
Vertical Pole Mount Bracket
DownloadQuick Start Guide
Hikvision PTZ Wall mount DS-1602ZJ
Wall Mount
Aluminum alloy
Hikvision White
Parameters
Description
Wall Mount Bracket In/Outdoor
Appearance
Hik white
Material
Aluminum alloy
Dimension
97.3 mm × 182.6 mm × 306.4 mm
(3.83” × 7.19” × 12.06”)
Weight
925 g (2.04 lb.)
DownloadQuick Start Guide
Hikvision Corner mount DS-1476ZJ-SUS
Corner Mount
Stainless Steel
Hikvision White
Parameters
Weight
2280 g (5.03 lb.)
Appearance
Hikvision White
Material
Stainless Steel
Dimension
250 mm × 126 mm × 105 mm (9.84" × 4.96" × 4.13")
Description
Corner Mount
Download
Quick Start Guide
Hikvision Vertical Pole Mount Bracket (2765/2785/2H65/2H85) - DS-1475ZJ-SUS
Vertical Pole Mount
Stainless Steel
Hikvision White
Parameters
Weight
1205 g (2.66 lb.)
Appearance
Hikvision White
Material
Stainless Steel
Dimension
250 mm × 127 mm × 46 mm (9.84" × 5" × 1.81")
Description
Vertical Pole Mount
Download
Quick Start Guide
Hikvision Wall Mount Bracket (2765/2785) DS-1473ZJ-155B
Wall Mount
With Junction Box
Aluminum alloy
Hikvision Black
Parameters
Description
Wall Mount for Dome Camera
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
Ø 155 mm × 243 mm × 300 mm (6.10" × 9.56" × 11.81" )
Weight
1750 g (3.86 lb.)
Download
Data Sheet
Hikvision Wall Mount Bracket With Integrated Junction Box (1753/2h46/2h66//2h86-no Pigtail Models) - DS-1473ZJ-135B
Wall Mount
With Junction Box
Aluminum alloy
Hikvision White
Parameters
Weight
1475 g (3.25 lb.)
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
Ø 136 mm × 242.92 mm × 290 mm (5.35" × 9.56" × 11.42")
Description
Wall Mount
Download
Quick Start Guide
Hikvision Pendant Mount Bracket (2785/2765) DS-1471ZJ-155
Pendant Mount for Dome Camera
Aluminum Alloy
Hikvision White
Parameters
Weight
Approx. 1400g (3.1 lb.)
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
Ø 155 mm × 546 mm (6.1" × 21.50")
Description
Pendant Mount for Dome Camera
Download
Data Sheet
Hikvision Pendant Mount DS-1471ZJ-135
Pendant Mount
Aluminum Alloy
Hikvision White
Parameters
Weight
1350 g (2.98 lb.)
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
Ø 136 mm × 565 mm (5.35" × 22.24")
Description
Pendant Mount
Download
Quick Start Guide
Hikvision Wall Mount Bracket Plastic For Mini PTZ (2955) - DS-1294ZJ
Wall Mount Bracket for PTZ Camera
Plastic & Steel
Hikvision White
Parameters
Weight
450g
Appearance
Hikvision White
Material
Toughened Plastic
Dimension
230×80×130mm
Description
Wall Mount Bracket forPTZ Camera
Download
Quick Start Guide
Hikvision Inclined Junction Box 360 Fisheye (6365/63C5) - DS-1281ZJ-DM25
Inclined Ceiling Mount Bracket for Dome Camera
Aluminum Alloy
Hikvision White
Parameters
Weight
300g
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
153×164×45mm
Description
Inclined Ceiling Mount Bracket for ,Dome Camera,
Download
Quick Start Guide
Hikvision Junction Box - DS-1280ZJ-DM8
Junction Box
Aluminum Alloy
Hikvision White
Parameters
Weight
Approx.: 210 g (0.46 lb.)
Appearance
Hikvision White
Material
Aluminum Alloy
Dimension
Φ126.7 mm × 35 mm (4.99" × 1.38")
Description
Junction Box for Dome Camera
Download
Quick Start Guide
