| Brand / Series |
Uniview UNV / LightHunter Dual-lens PTZ |
| Model (SKU) |
IPC94144SFW-X25-F40C |
| Panorama Channel |
4 MP 1/1.8″ CMOS; lens 4 mm F1.0; FOV(H/V/D) 94.9°/51.5°/116.7° |
| PTZ Channel |
4 MP 1/2.7″ CMOS; lens 4.8–120 mm F1.5–F3.8; 25× zoom; FOV(H) 55.46°–3.09° |
| Low-light / WDR |
LightHunter; 120 dB WDR; 2D/3D DNR; HLC; digital defog |
| Illumination |
PTZ IR up to 100 m (850 nm); Panorama warm-light up to 30 m |
| Streams / Codec |
Triple streams; Ultra 265 / H.265 / H.264 / MJPEG; ROI; U-code |
| Max Frame Rate |
Both channels up to 4 MP (2688×1520) @ 30 fps (per stream) |
| PTZ / Presets |
Pan 360°; Tilt −15°~90°; up to 80°/s; 1024 presets; patrol/route/home |
| Audio / I/O |
Two-way audio (1/1 audio I/O); built-in speaker; 2/1 alarm I/O; RS-485 |
| Storage |
microSD up to 256 GB; ANR/NAS |
| Network & Security |
IPv4/HTTPS/TLS; ONVIF S/G/T; up to 32 users |
| Power |
DC 12 V ±25% or PoE+ (IEEE 802.3at); Max 24 W |
| Protection / Env. |
IP66; −40 °C ~ +65 °C; ≤95% RH; 6 kV surge |
| Dimensions / Weight |
Φ163 × 304 mm; 2.27 kg |
| DORI (PTZ) |
At 4.8 mm: Detect 123.8 m / Identify 12.4 m; at 120 mm: Detect 2475 m / Identify 247.5 m |
| DORI (Panorama) |
4 mm: Detect 62.1 m / Identify 6.2 m |
