HiLook NVR‑104MH‑C/4P 4‑Channel PoE NVR, 4K HDMI, Up to 8 TB Support

Description

HiLook NVR‑104MH‑C/4P 4‑Channel PoE Network Video Recorder

The HiLook NVR‑104MH‑C/4P is a professional-grade 4-channel NVR with built-in PoE ports, capable of delivering high-performance recording and advanced smart analytics in a compact unit—perfect for small to medium surveillance setups.

Key Features

  • Up to 4 IP camera inputs with built-in PoE (IEEE 802.3af/at)
  • Supports efficient H.265+/H.265/H.264+/H.264 video compression
  • Simultaneous HDMI (up to 4K resolution) and VGA outputs
  • Smart VCA analytics: motion detection, line crossing, intrusion, heat map, ANPR, people counting
  • Supports up to 1‑ch @ 8 MP or 5‑ch @ 1080p decoding
  • Smart search and smart playback for quick video access
  • Expandable storage via one SATA bay—up to 8 TB HDD

Technical Specifications

Specification Details
IP Camera Inputs 4‑channel PoE (RJ‑45, IEEE 802.3af/at)
Max Incoming Bandwidth 40 Mbps
Video Decoding 1‑ch @ 8 MP (30 fps) or 5‑ch @ 1080p (30 fps)
Video Compression H.265+/H.265/H.264+/H.264
Smart VCA Functions Motion, line crossing, intrusion, heat map, ANPR, people counting
Video Output HDMI: up to 4K (4096×2160 @30 Hz); VGA: up to 1080p @60 Hz
Audio 1‑ch input (RCA), 1‑ch output (RCA); supports G.711ulaw/alaw, G.722, G.726
Storage 1 SATA (up to 8 TB HDD)
USB 2× USB 2.0 (rear panel)
Network 1× RJ‑45 10/100 Mbps + 4× PoE ports
Power Supply 48 VDC, 1.35 A
Power Consumption ≤ 10 W (without HDD, PoE off)
Operating Temp / Humidity –10 °C to 55 °C, 10 % to 90 % RH
Dimensions (W×D×H) 265 × 225 × 48 mm
Weight (without HDD) ≤ 1 kg

Why Choose This NVR?

  • Trusted HiLook NVR with comprehensive VCA analytics
  • Built‑in PoE simplifies camera setup
  • Future‑proof 4K HDMI output
  • Easy to navigate smart playback
  • Australian stock and support available

More Informations

HiLook NVR-104MH-C/4P Datasheet
HiLook NVR 7 Steps Setup
