Bosch CC500P — Solution 16i Hardwired Alarm Panel PCB (8/16 Zone, 4 Areas)

Description

Solution 16i · Hardwired · 16 Zone · 4 AreasSolution 16i Panel

Bosch CC500P Solution 16i Panel — Australian Stock & 3-Year Warranty

The Bosch CC500P (Solution 16i) is a hardwired control panel PCB for Australian homes and small commercial premises that need more partitioning than the Solution 2000/3000. It provides 8 to 16 fully programmable zones, up to 4 independent areas, 4 outputs (expandable), 32 users and support for up to 8 keypads. With a built-in PSTN dialler, 256-event log and enclosure-mount design, the CC500P is a robust multi-area panel backed by a 3-year Australian warranty.

Zones
8 / 16 Split
Areas
4 Partitions
Keypads
Up to 8
Users
32 Codes

Four Independent Areas

Partition the site into up to 4 areas — ideal for shared premises, tenancies or home-plus-office.

Eight Keypads

Place a codepad at every entry with support for up to 8 keypads across the system.

Expandable Outputs

Four onboard outputs expandable via zone expanders for sirens, strobes and automation.

Built-in Dialler

Onboard PSTN reporting with IP paths available for monitored Australian installations.

Technical Specifications
Model / SKU CC500P (BOSCC500P)
Series Bosch Solution 16i
Zones 8 / 16 split, fully programmable
Areas Up to 4 independent partitions
Outputs 4 (expandable)
Users 32 users
Keypads Up to 8
Event Log 256 events
Communications Built-in PSTN dialler
Mounting Enclosure mount (PCB)
Power 18 VAC
Weight 2.8 kg
Warranty 3 Years (Australia)

Downloads

CC500P DatasheetBosch Alarm Panel Quick Start GuideBosch Alarm Panel User Manual

Frequently Asked Questions

How is the Solution 16i different from the 2000/3000?
The 16i (CC500P) adds up to 4 areas and 8 keypads, suiting multi-tenancy or home-plus-office sites needing more partitioning.
Which keypads are compatible?
Bosch Solution-series codepads such as the CP-series LCD keypads; check the current 16i compatibility matrix for your model.
Is an enclosure included?
No. This is the PCB — mount it in a compatible Bosch metal enclosure with a plug-pack and backup battery.
Can it report over IP?
Yes. It includes a PSTN dialler, and IP reporting can be added with a compatible communication module.
How many zones can it handle?
8 to 16 fully programmable hardwired zones across up to 4 areas.
What power does it need?
18 VAC via a Bosch plug-pack, with a 12 V backup battery for mains-fail operation.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support

Bosch CC500P — Solution 16i Hardwired Alarm Panel PCB (8/16 Zone, 4 Areas)

Product form

SKU: CC500P

$159.00 Incl. GST

    • PayPal
    • Apple Pay
    • Visa
    • Mastercard
    • American Express
    • Zip
    • Afterpay

    Add Ons & Accessories

    • Shipped today? Order within: Jul 06, 2026 14:00:00 +1000
    • Warranty: 36 months
    • 30 day Money Back Guarantee
    • Australian Stocks & Express Delivery
    • Back-to-base Warranty & Tech Support
    • FREE Shipping over $180

    Description

    Solution 16i · Hardwired · 16 Zone · 4 AreasSolution 16i Panel

    Bosch CC500P Solution 16i Panel — Australian Stock & 3-Year Warranty

    The Bosch CC500P (Solution 16i) is a hardwired control panel PCB for Australian homes and small commercial premises that need more partitioning than the Solution 2000/3000. It provides 8 to 16 fully programmable zones, up to 4 independent areas, 4 outputs (expandable), 32 users and support for up to 8 keypads. With a built-in PSTN dialler, 256-event log and enclosure-mount design, the CC500P is a robust multi-area panel backed by a 3-year Australian warranty.

    Zones
    8 / 16 Split
    Areas
    4 Partitions
    Keypads
    Up to 8
    Users
    32 Codes

    Four Independent Areas

    Partition the site into up to 4 areas — ideal for shared premises, tenancies or home-plus-office.

    Eight Keypads

    Place a codepad at every entry with support for up to 8 keypads across the system.

    Expandable Outputs

    Four onboard outputs expandable via zone expanders for sirens, strobes and automation.

    Built-in Dialler

    Onboard PSTN reporting with IP paths available for monitored Australian installations.

    Technical Specifications
    Model / SKU CC500P (BOSCC500P)
    Series Bosch Solution 16i
    Zones 8 / 16 split, fully programmable
    Areas Up to 4 independent partitions
    Outputs 4 (expandable)
    Users 32 users
    Keypads Up to 8
    Event Log 256 events
    Communications Built-in PSTN dialler
    Mounting Enclosure mount (PCB)
    Power 18 VAC
    Weight 2.8 kg
    Warranty 3 Years (Australia)

    Downloads

    CC500P DatasheetBosch Alarm Panel Quick Start GuideBosch Alarm Panel User Manual

    Frequently Asked Questions

    How is the Solution 16i different from the 2000/3000?
    The 16i (CC500P) adds up to 4 areas and 8 keypads, suiting multi-tenancy or home-plus-office sites needing more partitioning.
    Which keypads are compatible?
    Bosch Solution-series codepads such as the CP-series LCD keypads; check the current 16i compatibility matrix for your model.
    Is an enclosure included?
    No. This is the PCB — mount it in a compatible Bosch metal enclosure with a plug-pack and backup battery.
    Can it report over IP?
    Yes. It includes a PSTN dialler, and IP reporting can be added with a compatible communication module.
    How many zones can it handle?
    8 to 16 fully programmable hardwired zones across up to 4 areas.
    What power does it need?
    18 VAC via a Bosch plug-pack, with a 12 V backup battery for mains-fail operation.
