Ubiquiti UNIFI SWITCHING · NDAA COMPLIANT
Compact 8-Port Layer 2 PoE+ Powerhouse
The Ubiquiti USW-Ultra is a ultra-compact, high-density 8-port Gigabit Ethernet Layer 2 switch featuring 7 PoE+ output ports and a total PoE availability budget of up to 202W when powered by the included 42W (no AC Adapter), 60W and 210W AC adapter. Designed for sleek tabletop, wall, or DIN-rail deployment, this versatile switch delivers enterprise-grade switching capacity to power IP cameras, access points, and VoIP phones in tight space deployments.
Port Count
8x GbE RJ45 Ports
PoE Availability
42W, 60W, 120W
Management
Managed Layer 2
Compliance
NDAA Compliant
Versatile Power Modes & Centralized Network Control
Engineered for complete adaptability, the USW-Ultra offers flexible power input options—capable of being powered via PoE++ or external AC power adapters depending on deployment requirements. Integrated into the centralized UniFi Network controller, administrators gain full control over port-level PoE settings, VLAN tagging, storm control, and real-time power consumption metrics from a unified interface.
Massive PoE Budget in Small Form Factor
Delivers up to 42W, 60W and 202W total PoE capacity to 7 802.3af/at PoE+ output ports, easily driving multiple high-power devices such as PTZ cameras, access points, and UniFi display panels.
Flexible Multi-Surface Mounting
Features a ultra-slim chassis designed for subtle mounting on walls, under desks, or on standard DIN-rails, making it ideal for utility closets, retail spaces, and AV cabinets.
Technical Specification Matrix
| Model |
USW-Ultra-42W / 60W / 210W |
| Networking Interfaces |
(8) 10/100/1000 Mbps RJ45 Ports |
| PoE Interfaces |
(1) PoE++ Input Port / (7) PoE+ Output Ports |
| Included Power Supply |
42W (no AC Adapter), 60W, 120W |
| Max PoE Output Budget |
42W (no Adapter), 52W and 202W (with included 60W and 210W PSU) |
| Total Non-Blocking Throughput |
8 Gbps |
| Switching Capacity |
16 Gbps |
| Enclosure Material |
Polycarbonate |
| Regulatory Compliance |
NDAA Compliant |
What is the maximum PoE budget when using the included 210W power supply?
When powered with the included 210W power supply, the USW-Ultra-210W delivers up to 202W of total available PoE output power across its 7 PoE+ ports.
Can the USW-Ultra-210W be powered via PoE instead of the AC adapter?
Yes, Port 1 supports PoE+ or PoE++ input. When powered via PoE++, it can provide an output PoE budget to downstream devices without using an AC power brick.
Is mounting hardware included with this switch?
Yes, the switch comes with wall-mounting hardware and support for magnetic or DIN-rail mounting options for flexible installation.
Is the USW-Ultra NDAA compliant?
Yes, the UniFi Ultra 210W Switch is officially NDAA compliant and suitable for commercial installations requiring NDAA adherence.
