TP-Link Omada ER7406 Multi-WAN Wired VPN Router
Overview
The TP-Link Omada ER7406 is a high-performance, rack-mountable wired VPN router built for small-to-medium businesses and enterprise branch deployments across Australia. With flexible multi-WAN support, hardware-accelerated VPN, and seamless integration into the Omada SDN ecosystem, the ER7406 delivers reliable, scalable connectivity for demanding commercial environments.
Description
Designed for professional installers and IT administrators, the ER7406 combines robust load balancing, failover redundancy, and centralised cloud management into a single 1U rack-mount unit. Whether you're deploying across a retail chain, school campus, or multi-site business, the ER7406 simplifies network management without compromising performance or security.
Key Features
- Up to 4 WAN ports (2 dedicated Gigabit WAN + 2 configurable WAN/LAN) for link aggregation and failover
- Hardware-accelerated VPN — supports IPsec, OpenVPN, L2TP, and PPTP protocols
- Centralised management via Omada SDN Controller (hardware, software, or cloud-based)
- Advanced load balancing and automatic WAN failover for maximum uptime
- Robust firewall with ACL, DoS defence, and IP/MAC/URL filtering
- VLAN support for network segmentation and guest network isolation
- 1U rack-mount form factor — ideal for server room and comms cabinet installations
- Zero-Touch Provisioning (ZTP) for rapid remote deployment
- Supports up to 150,000 concurrent sessions
- Compatible with the full Omada ecosystem — switches, access points, and controllers
Use Cases
-
Multi-site businesses: Centralise management of multiple branch offices with Omada Cloud Controller
-
Retail and hospitality: Segment guest Wi-Fi from POS and back-office networks using VLANs
-
Education: Enforce content filtering and manage bandwidth across student and staff networks
-
Commercial installers: Deploy and configure remotely via Zero-Touch Provisioning — no on-site visit required
-
SMB IT teams: Replace ageing routers with a scalable, cloud-managed solution that grows with the business
Specifications
| Specification |
Detail |
| Model |
ER7406 |
| WAN Ports |
2× Gigabit WAN + 2× configurable WAN/LAN (up to 4 WAN total) |
| LAN Ports |
4× Gigabit LAN (configurable) |
| USB Port |
1× USB 3.0 (3G/4G modem support) |
| VPN Protocols |
IPsec, OpenVPN, L2TP, PPTP |
| Max VPN Tunnels |
Up to 100 IPsec VPN tunnels |
| Concurrent Sessions |
150,000 |
| NAT Throughput |
Up to 2 Gbps |
| IPsec VPN Throughput |
Up to 800 Mbps |
| Form Factor |
1U Rack-Mount |
| Dimensions |
440 × 220 × 44 mm |
| Power Supply |
100–240 V AC, 50/60 Hz |
| Management |
Omada App, Omada Cloud Controller, Hardware Controller, Web UI |
| Certifications |
CE, FCC, RoHS |
| Operating Temperature |
0–40°C |
| Warranty |
3 Years (Australia) |
Official Videos
Watch the official TP-Link Omada ER7406 overview and setup guide on the TP-Link YouTube channel.
Recommended Accessories
-
Omada Hardware Controller (OC300 / OC200): On-premises SDN controller for managing the full Omada network stack
-
Omada PoE Switches (TL-SG2210MP / SG3428X): Managed PoE switches for access layer connectivity
-
Omada Wi-Fi 6 Access Points (EAP670 / EAP660 HD): High-density wireless for offices and hospitality venues
-
4G/LTE USB Modem: For WAN failover via the ER7406's USB 3.0 port
-
1U Rack-Mount Shelf or Cabinet: For secure comms room installation
Downloads
Frequently Asked Questions
Does the ER7406 require an Omada Controller to function?
No. The ER7406 can be managed as a standalone device via its local web UI. However, for multi-site deployments and advanced SDN features, an Omada Controller (hardware, software, or cloud) is recommended.
How many VPN tunnels does the ER7406 support?
The ER7406 supports up to 100 IPsec VPN tunnels simultaneously, making it well-suited for connecting multiple branch offices or remote workers.
Can I use a 4G/LTE modem as a WAN failover connection?
Yes. The ER7406 includes a USB 3.0 port that supports compatible 3G/4G USB modems, providing an additional WAN failover option when fixed-line connections are unavailable.
Is the ER7406 compatible with non-Omada network equipment?
Yes. The ER7406 functions as a standard wired router and is compatible with third-party switches and access points. Full SDN features, however, require Omada-compatible devices.
What is the difference between the ER7406 and the ER7206?
The ER7406 offers higher NAT throughput (up to 2 Gbps vs 1 Gbps on the ER7206), more concurrent sessions, and greater VPN throughput — making it the preferred choice for larger or higher-traffic deployments.
Is the ER7406 available with Australian warranty support?
Yes. TP-Link Australia provides a 3-year warranty on the ER7406, with local support available through authorised Australian resellers and the TP-Link AU support portal.
