TP-Link Omada EAP650GP Desktop Wi-Fi 6 Access Point with GPON
Overview
The TP-Link Omada EAP650GP is a desktop-form-factor Wi-Fi 6 (802.11ax) access point with a built-in GPON interface, purpose-built for fibre-connected small-to-medium business and enterprise environments. Combining AX3000 dual-band wireless performance with an integrated GPON ONU, it simplifies fibre-to-Wi-Fi deployments by eliminating the need for a separate optical network unit — ideal for hotels, offices, and multi-tenant buildings already running or planning GPON infrastructure.
Key Features
-
Wi-Fi 6 AX3000: 574 Mbps on 2.4 GHz + 2402 Mbps on 5 GHz for high-density, high-throughput wireless coverage.
-
Built-in GPON ONU: Integrated SC/APC optical interface connects directly to fibre infrastructure — no separate ONU required.
-
PoE In (802.3at): Powers the unit via a single Ethernet cable, reducing cabling complexity.
-
Omada SDN Compatible: Centralised management via Omada Hardware Controller, Software Controller, or Omada Cloud.
-
MU-MIMO & OFDMA: Serves multiple clients simultaneously for improved efficiency in busy environments.
-
BSS Colouring: Reduces co-channel interference in high-density Wi-Fi deployments.
-
WPA3 Security: Latest wireless encryption standard for enhanced network security.
-
Up to 4 SSIDs: Segment traffic across multiple networks (e.g. staff, guest, IoT).
-
Desktop Form Factor: Compact, unobtrusive design suited to reception desks, meeting rooms, and open-plan offices.
Use Cases
-
Hotels & Hospitality: Deploy per-room or per-floor Wi-Fi 6 coverage over existing GPON fibre runs without additional ONU hardware.
-
SMB Offices: Provide fast, reliable wireless for staff and guests from a single compact unit on a desk or shelf.
-
Multi-Tenant Buildings: Simplify fibre-to-Wi-Fi rollouts in apartments, co-working spaces, and serviced offices.
-
Education: Support high-density classroom or library environments with MU-MIMO and OFDMA efficiency.
-
Retail: Deliver reliable POS and guest Wi-Fi from a discreet desktop unit.
Specifications
| Specification |
Detail |
| Model |
EAP650GP |
| Wi-Fi Standard |
IEEE 802.11ax/ac/n/g/b/a (Wi-Fi 6) |
| Wireless Speed |
AX3000: 574 Mbps (2.4 GHz) + 2402 Mbps (5 GHz) |
| Frequency Bands |
2.4 GHz & 5 GHz (Dual-Band) |
| GPON Interface |
SC/APC, ITU-T G.984 (GPON) |
| Ethernet Ports |
1× Gigabit RJ45 (PoE In, 802.3at) |
| PoE In |
802.3at (PoE+), up to 30W |
| Antennas |
Internal |
| Max SSIDs |
4 per band (8 total) |
| Security |
WPA3, WPA2, WPA, WEP |
| Management |
Omada App, Omada Software Controller, Omada Hardware Controller, Omada Cloud |
| Form Factor |
Desktop |
| Power Supply |
PoE+ (802.3at) or passive PoE adapter (included) |
| Operating Temperature |
0–40°C |
| Dimensions |
197 × 197 × 36.5 mm |
| Certifications |
CE, RoHS, RCM (AU/NZ) |
Official Videos
Watch the official Omada EAP650GP overview and setup guide from TP-Link:
View Omada EAP650GP Videos on YouTube
Downloads
Frequently Asked Questions
Does the EAP650GP require a separate ONU or modem?
No. The EAP650GP has a built-in GPON ONU with an SC/APC optical port, so it connects directly to your fibre network without a separate optical network unit.
Can the EAP650GP be managed centrally?
Yes. It is fully compatible with the Omada SDN platform — manage it via the Omada Software Controller, Hardware Controller (e.g. OC300), or Omada Cloud for zero-touch provisioning and centralised monitoring.
Does it support PoE?
Yes. The EAP650GP accepts 802.3at (PoE+) power input on its Gigabit RJ45 port, allowing it to be powered by a compatible PoE switch or injector without a separate power adapter.
How many SSIDs can I create?
Up to 4 SSIDs per band (8 total), allowing you to segment traffic for staff, guests, IoT devices, and more.
Is the EAP650GP suitable for Australian fibre networks?
Yes. It supports standard GPON (ITU-T G.984) and carries RCM certification for the Australian and New Zealand markets.
What is the difference between the EAP650GP and a standard EAP650?
The EAP650GP adds an integrated GPON ONU interface, making it ideal for fibre-connected deployments where a standard EAP650 would require a separate ONU device.
