An 8-port, Layer 2 PoE switch supporting silent fanless cooling.Features:
(4) GbE, PoE+ RJ45 ports
(4) GbE RJ45 ports
52W total PoE supply*
Wall-mountable (kit included)
Managed with the UniFi Network application: Version 7.2.94 and later
*With an external 60W power adapter.
Technical Specifications
Mechanical
Dimensions
99.6 x 163.7 x 31.7 mm (4 x 6.4 x 1.3")
Weight
295 g (10.4 oz)
Enclosure material
Polycarbonate
Hardware
Management interface
Ethernet In-Band
Networking interface
(8) GbE RJ45 ports
PoE interface
(4) PoE/PoE+ (Pins 1, 2+; 3, 6-)
Total non-blocking throughput
8 Gbps
Switching capacity
16 Gbps
Power method
54V DC, 1.1A power adapter
Power supply
54V, external, 60W
Supported voltage range
50—57V DC
Max. power consumption
8W (Excluding PoE output)
Total available PoE
52W**With an external 60W power adapter.
Max. PoE wattage per port by PSE
PoE+: 30W
Button
Factory reset
Ambient operating temperature
-15 to 40° C (5 to 104° F)
Ambient operating humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
Switching Features
Layer 2 features
IGMP snoopingSTP / RSTP with priorities and port-level disablePort isolationStorm controlVoice VLANPort mirroringLACP port aggregationMulticast / broadcast rate limitingMAC address blockingFlow control802.1X controlJumbo framesProprietary loop protectionDHCP snooping / guardingEgress rate limitLLDP-MEDPort restricted by MACDevice isolation with ACLs
Layer 3 features
–
LEDs
System
Status
Ethernet
PoESpeed/link/activity
PoE
Link/activity
Application Requirements
UniFi Network
Version 7.2.94 and later
Downloads
DatasheetInstallation Guide
A wall-mountable*, 16-port, Layer 2 PoE switch with a fanless cooling system.Features:
(8) GbE, PoE+ RJ45 ports
(8) GbE RJ45 ports
45W total PoE availability
Managed with the UniFi Network application: Version 7.2.94 and later
*Kit included.
Downloads
Datasheet
Installation Guide
All-in-one, enterprise-grade UniFi OS Console and security gateway designed to host the full UniFi application suite.Connect the Dream Machine Pro with a USP RPS to create an uninterruptible network.Features:
Pre-installed UniFi Network application
LAN ports: (8) GbE RJ45, (1) 10G SFP+
WAN ports: (1) GbE RJ45, (1) 10G SFP+
Threat management and traffic/client identification
(1) 3.5" HDD bay for storing UniFi Protect recordings
Downloads
Datasheet
Installation Guide
Layer 2 switch with (5) GbE RJ45 ports, including (1) 802.3af PoE input.The Switch Flex Mini (USW Flex Mini) is a fully managed, Layer 2 switch with (5) GbE RJ45 ports, including (1) 802.3af PoE input. The USW Flex Mini can be powered with either PoE (via Port 1) or its included USB-C power adapter*. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.Features:
(1) GbE, 802.3af PoE RJ45 input
(4) GbE RJ45 ports
Compact, slim housing
Can be powered with a 5V, 1A USB-C adapter (Only Comes In Single Pack)
Downloads
Datasheet
Installation Guide
The USW-24-POE is a configurable Gigabit Layer 2 switch with twenty-four Gigabit Ethernet ports including sixteen auto-sensing 802.3at PoE+ ports, and two SFP ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network. The USW-24-POE features a 1.3" touch LCM to provide status information. With a depth of 7.9", the compact fanless design can be easily installed in a SOHO rack cabinet.Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-24-POE offers an extensive suite of advanced Layer 2 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.
The USW Flex Utility is an outdoor weatherproof enclosure designed for use with the UniFi Switch Flex, USW-Flex. It includes an Ethernet patch cable and a 60W PoE adapter, which provides a maximum PoE budget of 46W. The USW Flex Utility can be easily mounted on a pole, provides clean cable management and screw lock for security.
Downloads
Datasheet
UniFi Pro Aggregation Switch
The Switch Pro Aggregation is a fully managed, Layer 3 switch with (28) 10G SFP+ ports and (4) 25G SFP28 ports designed to enhance your network's switching capacity and performance by creating high-bandwidth aggregation links. This rack-mountable switch also offers 760 Gbps switching capacity and features a 1.3" LCM color touchscreen that concisely displays key system and connection insights.Additionally, the Switch Pro Aggregation offers enhanced power supply failure protection when connected to the SmartPower Redundant Power System (USP RPS sold separately). This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
(1) 1.3” LCM color touchscreen with AR switch management
(28) 10G SFP+ ports
(4) 25G SFP28 ports
(1) USP RPS DC input
760 Gbps switching capacity
Layer 3 switching features
Mechanical
Dimensions 442 x 325 x 44 mm
(17.4 x 12.8 x 1.7")
Weight Without Mount: 4.6 kg (10.14 lb)
With Mount: 4.7 kg (10.36 lb)
Enclosure Material SGCC Steel
Hardware
Total Non-Blocking Throughput 380 Gbps
Switching Capacity 760 Gbps
Forwarding Rate 565.44 Mpps
Max. Power Consumption 100W
Power Method (1) Universal AC input, 100-240VAC, 2A Max, 50/60 Hz
(1) USP-RPS DC input, 11.5VDC, 8.7A
Power Supply AC/DC, Internal, 100W
Network Interface (28) 1/10 Gbps SFP+ Ethernet
(4) 1/10/25 Gbps SFP28 Ethernet*
LCM Display (1) 1.3" Touchscreen
Management Interface Ethernet In-Band
Modes SMB Layer 3 10/25 G Fiber Switch
ESD/EMP Protection Air: ± 16kV, Contact: ± 12kV
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 10 - 90% Noncondensing
*The four SFP28 ports don't support mixed speed at 25Gbps mode.
Once one of the SFP28 ports is configured at 25Gbps mode, the others will be limited at 25Gbps too.
The SFP28 ports only support mixed speed when all ports are at 1Gbps or 10Gbps.
Downloads
Datasheet
Installation Guide
Layer 2 switch with (5) GbE RJ45 ports, including (1) 802.3af PoE input.The Switch Flex Mini (USW Flex Mini) is a fully managed, Layer 2 switch with (5) GbE RJ45 ports, including (1) 802.3af PoE input. The USW Flex Mini can be powered with either PoE (via Port 1) or its included USB-C power adapter*. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
(1) GbE, 802.3af PoE RJ45 input(4) GbE RJ45 portsCompact, slim housingCan be powered with a 5V, 1A USB-C adapter (Only Comes In Single Pack)
Layer 2, PoE switch with (48) GbE, PoE+ and 24V passive PoE RJ45 ports, (2) 1G SFP ports, and (2) 10G SFP+ ports.The Switch 48 PoE 500W (US 48 PoE 500W), a fully managed switch with (48) GbE RJ45 ports, (2) 1G SFP ports, and (2) 10G SFP+ ports. Each of the switch's ports can provide either PoE+ or configurable, 24V passive PoE to UniFi access points or other PoE devices. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.Features:
(48) GbE, PoE+ and 24V passive PoE RJ45 ports
(2) 1G SFP ports
(2) 10G SFP+ ports
500W total PoE supply
Managed with the UniFi Network application
Downloads
Datasheet Quick Start Guide
Layer 3, PoE switch with (24) GbE RJ45 ports, including (16) 802.3at PoE+ ports and (8) 802.3bt PoE++ ports, and (2) 10G SFP+ ports.The Switch Pro 24 PoE (USW Pro 24 PoE) is a fully managed switch with (16) GbE, 802.3at PoE+ RJ45 ports, (8) GbE, 802.3bt PoE++ RJ45 ports, and (2) 10G SFP+ ports. The USW Pro 24 PoE combines a rich set of Layer 2 features with advanced Layer 3 tools including inter-VLAN routing, static routing, and a DHCP server. The USW Pro 24 PoE is the ideal access layer switch for any UniFi system. It combines up to 400W of PoE power with SmartPower RPS (USP RPS) power redundancy. The switch can also be monitored and configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.Features:
(1) 1.3" LCM color touchscreen with AR switch management
(16) GbE, 802.3at PoE+ RJ45 ports
(8) GbE, 802.3bt PoE++ RJ45 ports
(2) 10G SFP+ ports
(1) USP RPS DC input
400W total PoE supply
Near-silent cooling
Layer 3 switching features
Managed with the UniFi Network application: Version 5.10.5 and later
Downloads
Datasheet Installation Guide
The USW-16-POE is a configurable Gigabit Layer 2 switch with sixteen Gigabit Ethernet ports including eight auto-sensing 802.3at PoE+ ports, and two SFP ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network. The USW-16-POE features a 1.3" touch LCM to provide status information. With a depth of 7.9", the compact fanless design can be easily installed in a SOHO rack cabinet.Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-16-POE offers an extensive suite of advanced Layer 2 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.
Flexible five-port, Layer 2 PoE switch that can be powered with PoE++.Features:
(1) GbE, PoE++ RJ45 input
(4) GbE, PoE+ RJ45 ports
Up to a 46W total PoE supply*
Weatherproof design with multiple mounting options
Managed with the UniFi Network application: Version 5.10.3 and later
*When powered with a PoE++ switch or a 60W PoE adapter (sold separately).
DownloadsDatasheet Installation Guide
Layer 3 switch with (24) 10GbE RJ45 ports and (2) 25G SFP28 ports.The Switch Enterprise XG 24 (USW Enterprise XG 24) is a fully managed, mult-gigabit, Layer 3 switch with (24) 10GbE RJ45 ports and (2) 25G SFP28 ports. The USW Enterprise XG 24 also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights.Additionally, the USW Enterprise XG 24 offers enhanced power supply failure protection when connected to the SmartPower Redundant Power System (USP RPS sold separately). This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.Features:
(1) 1.3" LCM color touchscreen with AR switch management
(24) 10GbE RJ45 ports
(2) 25G SFP28 ports
(1) USP RPS DC input
Layer 3 switching features
Single-row RJ45 port layout for easy patch panel cable management
Downloads
Datasheet Installation Guide
Compact but powerful switch with (5) Gigabit PoE ports and an intuitive EdgeSwitch XP interface.Introducing the Advanced Power over Ethernet Switches, EdgeSwitch™ XP from Ubiquiti. EdgeSwitch XP delivers reliable passive PoE and fast 10/100/1000 Mbps connectivity to attached Ubiquiti devices and other devices that support passive PoE. To connect your PoE devices, simply enable PoE in the easy-to-use EdgeSwitch XP Configuration Interface. Each port can be individually configured to provide PoE, so both PoE and non‑PoE devices can be connected.Features:
5 Gigabit PoE Ports
24V Configurable Passive PoE
EdgeSwitch XP Configuration Interface
Wall-Mountable
Downloads
Datasheet
Installation Guide
The Switch Flex XG (USW Flex XG) is a fully managed, mult-gigabit, Layer 2 switch with (4) 10GbE RJ45 ports and (1) GbE PoE input. The USW Flex XG sports slim, compact housing and can be mounted on a desktop*. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.Features:
(1) GbE, 802.3at PoE+ RJ45 input
(4) 10GbE RJ45 ports
Compact, slim housing
Can be powered with a 5V, 5A USB-C adapter
* Fanless Switch, Do not stack other hardware on the USW Flex XG, will affect heat dissipation
Downloads
Datasheet
Installation Guide
Layer 3, PoE switch with (8) 2.5GbE, 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports.The Switch Enterprise 8 PoE (USW Enterprise 8 PoE) is a fully managed, Layer 3* switch with (8) 2.5GbE, 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports.The USW Enterprise 8 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.Features:
(1) 1.3" LCM color touchscreen with AR switch management
(8) 2.5GbE, 802.3at PoE+ RJ45 ports
(2) 10G SFP+ ports
120W total PoE supply
Wall-mountable (kit included)
* Layer 3 switching will become available in a future firmware update.
Managed with the UniFi Network application: Version 6.3.51 and later
Downloads
Datasheet
Installation Guide
Managed Layer 3 switch with (12) 2.5G RJ45 ports with PoE+ for WiFi 6 APs, (12) Gigabit RJ45 ports with PoE+, and (2) 10G SFP+ ports for fiber uplinks.Configurable Gigabit Layer 3 switch with auto-sensing 802.3at PoE+. It offers (12) 2.5G RJ45 Ethernet ports, (12) 1G RJ45 Ethernet ports, and (2) 10G SFP+ ports, providing 2.5G PoE links to your WiFi 6 APs and 10G fiber uplinks to your network. Features include a 1.3" touchscreen, single-row RJ45 port layout for easy patch panel cable management, and UniFi SmartPower Redundant Power System* (USP-RPS) support for intelligent protection from internal PSU interruption or failure.Features:
(12) 2.5G 802.3af/at PoE+ RJ45 ports
(12) 1G 802.3af/at PoE+ RJ45 ports
(2) 10G SFP+ ports
400W total PoE capacity
1.3" touchscreen with AR switch management
UniFi SmartPower RPS DC input
Managed with UniFi Network Application Version: 5.14.12 or higherMechanical
Dimensions 442.4 x 43.7 x 325 mm (17.4 x 1.7 x 12.8")
Weight Without Mount: 5.11 kg (11.27 lb)
With Mount: 5.2 kg (11.46 lb)
Enclosure Materials SGCC Steel
Mount Material SGCC Steel
Hardware
Total Non-Blocking Throughput 62 Gbps
Switching Capacity 124 Gbps
Forwarding Rate 92.25 Mpps
Max. Power Consumption 550W
Power Method (1) Universal AC input: 100-240VAC, 8.5A Max., 50/60 Hz
(1) USP-RPS DC input: 52VDC, 7.7A; 11.5VDC, 8.7A
Power Supply AC/DC, Internal, 550W
Management Interface Ethernet In-Band
Networking Interfaces (12) 10/100/1000 Mbps RJ45 Ethernet
(12) 100/1000/2500 Mbps RJ45 Ethernet
SFP+ Interfaces (2) 1/10G SFP+
PoE Interfaces (24) PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
Max. PoE+ Wattage per Port by PSE 34.2W
Voltage Range 802.3af Mode 44 to 57V
Voltage Range 802.3at Mode 50 to 57V
Services SMB Layer 3 PoE Gigabit Ethernet Switch
ESD/EMP Protection Air: ± 16 kV, Contact: ± 12 kV
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 10 - 95% Noncondensing
Certifications CE, FCC, IC
Ubiquiti Pro Max 48, 48-port, Layer 3 Etherlighting Switch, 2.5 GbE, 16 GbE RJ45 Ports, 32 GbE RJ45 , 4 10G SFP+, Throughput 112 Gbps
A 48-port, Layer 3 Etherlighting™ switch with 2.5 GbE.
Etherlighting™ ports that illuminate to indicate port location, speed/link, and native VLAN/network* (16) 2.5 GbE RJ45 ports (32) GbE RJ45 ports (4) 10G SFP+ ports DC power backup ready Managed with UniFi Network 8.0.24 and later*Pair with UniFi Etherlighting Patch Cables for optimal brightness.
Technical Specifications
Mechanical
Dimensions
442 x 325 x 44 mm (17.4 x 12.8 x 1.7")
Weight
Without mounting brackets: 4.8 kg (10.6 lb)With mounting brackets: 4.9 kg (10.8 lb)
Enclosure material
SGCC steel
Hardware
Management interface
Ethernet In-Band
Networking interface
(32) GbE RJ45 ports(16) 1/2.5 GbE RJ45 ports(4) 10G SFP+ ports
Total non-blocking throughput
112 Gbps
Switching capacity
224 Gbps
Power method
(1) Universal input, 100—240V AC, 50/60 Hz(1) USP-RPS DC input
Power supply
AC/DC, internal, 100W
Supported voltage range
100—240V AC
Max. power consumption
100W
LCM display
(1) 1.3" touchscreen
Button
Factory reset
Ambient operating temperature
-5 to 40° C (23 to 104° F)
Ambient operating humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
Switching Features
Layer 2 features
IGMP snoopingSTP / RSTP with priorities and port-level disablePort isolationStorm controlVoice VLANPort mirroringLACP port aggregationMulticast / broadcast rate limitingMAC address blockingFlow control802.1X controlJumbo framesProprietary loop protectionDHCP snooping / guardingEgress rate limitLLDP-MEDPort restricted by MACDevice isolation with ACLs
Layer 3 features
DHCP for locally-managed networksDHCP relayInter-VLAN routing between networks on same switchStatic routing between local networksNetwork isolation with ACLs
Etherlighting™
Ethernet
LocatingSpeed/linkNative VLAN/network
SFP+
LocatingSpeed/linkNative VLAN/network
LEDs
System
Status
RPS
Status
Application Requirements
UniFi Network
Version 8.0.24 and later
Downloads
USW-PRO-MAX-48 Installation Guide
Ubiquiti Pro Max 24, 24-port, Layer 3 Etherlighting Switch, 2.5 GbE, 16 GbE RJ45 Ports, 16 GbE RJ45 2 10G SFP+, Throughput 56 Gbps, USW-Pro-Max-24
A 24-port, Layer 3 Etherlighting™ switch with 2.5 GbE.
Etherlighting™ ports that illuminate to indicate port location, speed/link, and native VLAN/network* (8) 2.5 GbE RJ45 ports (16) GbE RJ45 ports (2) 10G SFP+ ports DC power backup ready Managed with UniFi Network 8.0.24 and later*Pair with UniFi Etherlighting Patch Cables for optimal brightness.
Technical Specifications
Mechanical
Dimensions
442 x 325 x 44 mm (17.4 x 12.8 x 1.7")
Weight
Without mounting brackets: 4.2 kg (9.3 lb)With mounting brackets: 4.3 kg (9.5 lb)
Enclosure material
SGCC steel
Hardware
Management interface
Ethernet In-Band
Networking interface
(16) GbE RJ45 ports(8) 1/2.5 GbE RJ45 ports(2) 10G SFP+ ports
Total non-blocking throughput
56 Gbps
Switching capacity
112 Gbps
Power method
(1) Universal input, 100—240V AC, 50/60 Hz(1) USP-RPS DC input
Power supply
AC/DC, internal, 50W
Supported voltage range
100—240V AC
Max. power consumption
50W
LCM display
(1) 1.3" touchscreen
Button
Factory reset
Ambient operating temperature
-5 to 40° C (23 to 104° F)
Ambient operating humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
Switching Features
Layer 2 features
IGMP snoopingSTP / RSTP with priorities and port-level disablePort isolationStorm controlVoice VLANPort mirroringLACP port aggregationMulticast / broadcast rate limitingMAC address blockingFlow control802.1X controlJumbo framesProprietary loop protectionDHCP snooping / guardingEgress rate limitLLDP-MEDPort restricted by MACDevice isolation with ACLs
Layer 3 features
DHCP for locally-managed networksDHCP relayInter-VLAN routing between networks on same switchStatic routing between local networksNetwork isolation with ACLs
Etherlighting™
Ethernet
LocatingSpeed/linkNative VLAN/network
SFP+
LocatingSpeed/linkNative VLAN/network
LEDs
System
Status
RPS
Status
Application Requirements
UniFi Network
Version 8.0.24 and later
Downloads
USW-Pro-Max-24 Installation Guide
High-performance WiFi 6 GPON CPE.The UFiber WiFi6 GPON CPE (UF WiFi6) is a point-to-multipoint WiFi 6 device that creates high-speed GPON connections capable of reaching a 2.4 Gbps downstream rate and 1.2 Gbps upstream rate. The UF WiFi6 has (4) GbE RJ45 LAN ports and (1) GPON WAN port to connect a local fiber line. It also excels at establishing reliably strong, long-distance fiber links up to 20 kilometers, allowing you to extend your service range and build your customer base.Features:
2x2, high-efficiency WiFi 6
2.4 GHz band (2x2 MIMO) with a 300 Mbps radio rate
5 GHz band (2x2 MU-MIMO and OFDMA) with a 1.2 Gbps radio rate
2.4 Gbps max downstream line rate
1.2 Gbps max upstream line rate
Establishes GPON links up to 20 km
Powerful Layer 2/3 management features
(1) GPON WAN port
(4) GbE RJ45 LAN ports
Powered with the included power adapter or passive PoE
Internal WiFi 6 (802.11ax) antennas
The USW-24 is a configurable Layer 2 switch with 24 Gigabit Ethernet ports and 2 SFP ports. The SFP ports provide 1 Gbps fiber uplink options to your enterprise network. The USW-24 features a 1.3" touchscreen, compact size, and fanless design. The touchscreen displays the current switch state and information for quick diagnosis. Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-24 switch offers an extensive suite of advanced Layer 2 switching protocols and features, including operating mode (switching, mirroring, or aggregate) per port.Features:
(24) Gigabit Ethernet Ports
(2) Gigabit SFP Ports
1.3" color touchscreen for status information
Managed by UniFi Network Controller
Product Specifications
USW-24
Dimensions 442.4 x 200 x 43.7 mm
(17.42 x 7.87 x 1.72")
Weight
With Rackmount Brackets 2.70 kg (5.95 lb)
2.79 kg (6.15 lb)
Interfaces 0
Interfaces
Networking
Management
(24) 10/100/1000 RJ45 Ports
(2) 1G SFP Ethernet Ports
Ethernet In-Band
Power Method 100-240VAC, 50/60 Hz, Universal Input
Power Supply AC/DC, Internal, 36W
Supported Voltage Range 100 to 240VAC
Max. Power Consumption 25W
LEDs
RJ45 Data Ports
SFP Data Ports
Speed/Link/Activity
Link/Activity
ESD/EMP Protection Air: ± 16 kV, Contact: ± 12 kV
Shock and Vibration ETSI300-019-1.4 Standard
Operating Temperature -5 to 45° C (23 to 113° F)
Operating Humidity 10 to 90% Noncondensing
Certifications CE, FCC, IC
UniFi Switch Pro 48 is a fully managed Layer 3 switch with (48) Gigabit Ethernet ports. (4) 10G SFP+ uplinks offer link aggregation for higher capacity and increased availability.The UniFi Switch Pro 48 features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server. The UniFi Switch Pro 48 is an ideal aggregation and access layer switch for any UniFi solution – it combines innovative near-silent cooling with UniFi SmartPower RPS power redundancy. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere.Features:
(48) Gigabit RJ45 ports
(4) 10G SFP+ ports
Layer 2 and Layer 3* features
UniFi SmartPower RPS DC input
Near-silent cooling
1.3" touchscreen display
Managed by UniFi Network Controller
* Available in future firmware upgrade.
UniFi Switch Pro 24 is a fully managed Layer 3 switch with (24) Gigabit Ethernet ports. (2) 10G SFP+ uplinks offer link aggregation for higher capacity and increased availability. The UniFi Switch Pro 24 features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server. The UniFi Switch Pro 24 is an ideal aggregation and access layer switch for any UniFi solution – it combines innovative near-silent cooling with UniFi SmartPower RPS power redundancy. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere.Features
(24) Gigabit RJ45 ports
(2) 10G SFP+ ports
Layer 2 and Layer 3* features
UniFi SmartPower RPS DC input
Near-silent cooling
1.3" touchscreen display
Managed by UniFi Network Controller
A 48-port, Layer 2 switch with a silent, fanless cooling system.Features:
(48) GbE RJ45 ports
(4) 1G SFP ports
1.3" LCM color touchscreen with AR switch management
Managed with the UniFi Network application: Version 7.2.94 and later
Downloads
Datasheet
Installation Guide
UniFi Aggregation SwitchUSW-Aggregation is a managed Layer 2 switch with eight 10G SFP+ ports, offering link aggregation for higher capacity and increased availability. USW-Aggregation features Layer 2 capabilities and supports highbandwidth links, making it ideal for aggregation switching to any UniFi solution that deploys various interconnect topologies. Built-in 36W AC/DC power supply can support copper Ethernet UF-RJ45-10G modules (sold separately) in all eight ports.
MechanicalDimensions 442.4 x 120 x 43.7 mm (17.42 x 4.72 x 1.72")Weight Without Mount: 2.65 kg (5.84 lb)With Mount: 2.74 kg (6.04 lb)Enclosure Material SGCCSteel
HardwareTotal Non-Blocking Throughput 80 GbpsSwitching Capacity 160 GbpsForwarding Rate 119.04 MppsMax. Power Consumption 30WPower Method Universal AC Input: 100-240VAC, 50/60 HzPower Supply AC/DC, Internal, 36WManagement Interface EthernetIn-BandModes SMB Layer 2 GigabitEthernetSwitchESD/EMP Protection Air: ± 16kV, Contact: ± 12kVOperating Temperature -5 to 40° C(23 to 104° F)Operating Humidity 10 - 90%NoncondensingCertications CE, FCC, IC
Ubiquiti UISP Switch, 8-Port GbE Switch w/ 27V Passive PoE, For MicroPoP Applications, 110W PoE Budget, Fanless, Layer 2 Switching NHU-UISP-S
Gigabit PoE switch for MicroPoP applications.Ideal for wireless ISP (WISP) deployments, the UISP® Switch is a fanless, Layer 2 PoE switch with (8) GbE RJ45 ports and (1) 1G SFP port for an additional fiber uplink option. The UISP Switch is a cost-effective solution for WISPs looking to quickly and inexpensively deliver Gigabit wireless speeds to their customers. With its hefty 110W total PoE supply, the UISP Switch delivers substantial power to every radio in your service network. For larger deployments, pair it with the UISP Console to create a cohesive routing and switching hub. The UISP Switch is managed with the UISP application, a centralized platform where you can monitor and manage all of your UISP devices.Features:
(8) GbE RJ45 ports with 27V passive PoE that support 2-pair and 4-pair modes
(1) 1G SFP port
110W PoE supply when powered with the included AC/DC adapter
Fanless, thermal cooling for silent operation
Wall-mountable (kit included)
Layer 2 switching features
Easy, Bluetooth-powered setup via the UISP Mobile app
Managed with the UISP application: Version 1.4.0-beta.11 and later
Downloads
Datasheet
Installation Guide
8 RJ45 GbE ports with PoE output support (both 802.3af/at and passive 24V) and two 1G SFP ports
Fanless design with removable mounting ears
Same features as existing EdgeSwitch models (extensive L2 features and basic L3 features)
Full line-rate performance for all ports simultaneously (i.e., 10 Gbps "throughput", 20 Gbps "capacity", or 14.88 Mpps "rate")
DC power input support: Terminal block for 42V to 56V DC input
Power consumption max 20W (excluding PoE output)
RJ45 serial console port
Operating temperature range depending on power input and load: ◦AC input up to 150W: -25C to 45C
AC input up to 100W: -25C to 55C
DC input: -25C to 60C
Advanced Switching Technology for the MassesBuild and expand your network with Ubiquiti Networks® EdgeSwitchTM, part of the EdgeMAX® line of products. The EdgeSwitch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks.The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.Switching PerformanceThe EdgeSwitch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss
The Ubiquiti Rack mount EdgeSwitch 48 500W ES-48-500W delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.
Two SFP ports support uplinks of up to 1 Gbps. For high-capacity uplinks this 48-port model includes two SFP+ ports for uplinks of up to 10 Gbps
The EdgeSwitch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks. The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.Ubiquiti EdgeSwitch ES-48-500W Key Features
(48) Gigabit RJ45 ports
(2) SFP ports
(2) SFP+ ports
Total, non-blocking throughput: 70 Gbps
Maximum power consumption: 500W
Supports POE+ IEEE 802.3at/af and 24V Passive PoE
Rackmountable
Australian AU-style power cable included
The Ubiquiti Rackmount EdgeSwitch 24 250W ES-24-250W delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.
The EdgeSwitch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks. The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.Ubiquiti EdgeSwitch ES-24-250W Key Features
(24) Gigabit RJ45 ports
(2) SFP ports
Total, non-blocking throughput: 26 Gbps
Maximum power consumption: 250W
Supports POE+ IEEE 802.3at/af and 24V Passive PoE
Rackmountable
Australian AU-style power cable included
Dual-band, 802.11ac Wave 2 access point with a 2+ Gbps aggregate throughput rate that can be plugged into any non-AC wall outlet.
The Access Point In-Wall HD (UAP IW HD) is a dual-band, 802.11ac WiFi access point that can be plugged into any non-AC wall outlet. The UAP IW HD can reach a 2+ Gbps aggregate throughput rate with its 5 GHz (4x4 MU-MIMO) and 2.4 GHz (2x2 MIMO) bands, which allows it to support over 200 concurrently connected clients. This access point is powered by PoE* and is equipped with (5) GbE RJ45 ports, including one for configurable 48V PoE passthrough. The UAP IW HD is the perfect plug-and-play access point for those looking for an easy-to-use, inconspicuous way to broaden their wireless coverage. It can be set up in minutes and fully managed with the UniFi Network web application or mobile app.
Features:
5 GHz (4x4 MU-MIMO) band with a 1.733 Gbps throughput rate
2.4 GHz (2x2 MIMO) band with a 300 Mbps throughput rate
200+ concurrent client capacity
Powered by PoE*
(5) GbE RJ45 ports, including (1) for configurable PoE passthrough (Port 1)
Managed with the UniFi Network application
Downloads
Datasheet
Installation Guide
Ubiquiti UniFi 48 port Managed Gigabit Layer2 & Layer3 switch - 48x Gigabit Ethernet Ports w/ 32x 802.3at POE+, 4x SFP Port Touch Display 210WThe USW-48-PoE is a configurable Gigabit Layer 2 switch with 48 Gigabit Ethernet ports including 32 auto-sensing 802.3at PoE+ ports, and 4 SFP ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network. The USW-48-PoE features a 1.3" touch LCM to provide statusManaged and configured by the UniFi Network Controller with UniFi mobile app support, the USW-48-PoE offers an extensive suite of advanced Layer 2 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.A 48-port, Layer 2 PoE switch with a silent, fanless cooling system.Features:
(32) GbE, PoE+ RJ45 ports
(16) GbE RJ45 ports
(4) 1G SFP ports
195W total PoE availability
1.3" LCM color touchscreen with AR switch management
Managed with the UniFi Network application: Version 7.2.94
Management
(48) 10/100/1000 RJ45 Ports
(4) 1G SFP Ethernet Ports
Ethernet In-Band
Power Method 100-240VAC, 50/60 Hz, Universal Input
Power Supply AC/DC, Internal, 240W
Supported Voltage Range 100 to 240VAC
Max. Power Consumption (Excluding PoE Output) 45W
LEDs
RJ45 Data Ports
SFP Data Ports
PoE; Speed/Link/Activity
Link/Activity
ESD/EMP Protection Air: ± 16 kV, Contact: ± 12 kV
Shock and Vibration ETSI300-019-1.4 Standard
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 10 to 90% Noncondensing
Certifications CE, FCC, IC
POE
PoE Interfaces
Ports 1-32
POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
Max. PoE Wattage per Port by PSE
802.3at
32W
Voltage Range 802.3af Mode 44-57V
Voltage Range 802.3at Mode 50-57V
Downloads
Datasheet
Installation Guide
THE SWITCH PRO 48 POE (USW PRO 48 POE) IS A FULLY MANAGED SWITCH WITH (40) GBE, POE+ RJ45 PORTS, (8) GBE, POE++ RJ45 PORTS, AND (4) 10G SFP+ PORTS.
The USW Pro 48 PoE combines a rich set of Layer 2 features with advanced Layer 3 tools including inter-VLAN routing, static routing, and a DHCP server. The USW Pro 48 PoE is the ideal access layer switch for any UniFi system. It combines up to 600W of PoE power with SmartPower RPS (USP RPS) power redundancy. The switch can also be monitored and configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
FEATURES:
(1) 1.3" LCM color touchscreen with AR switch management
(40) GbE, PoE+ RJ45 ports
(8) GbE, PoE++ RJ45 ports
(4) 10G SFP+ ports
(1) USP RPS DC input
600W total PoE supply
Near-silent cooling
Layer 3 switching features
Managed with the UniFi Network application: Version 5.10.5 and later
The Switch Enterprise 48 PoE (USW Enterprise 48 PoE) is a fully managed switch with (48) 2.5GbE, 802.3at PoE+ RJ45 ports, (4) 10G SFP+ ports, and a 720W total PoE supply. Along with its Layer 3 functionality, this switch offers an extensive suite of Layer 2 switching protocols, including port-specific operation modes (switching, mirroring, or aggregate).The USW Enterprise 48 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights.Additionally, the USW Enterprise 48 PoE offers enhanced power supply failure protection when connected to the SmartPower Redundant Power System (USP RPS sold separately). This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.Features:
(1) 1.3" LCM color touchscreen with AR switch management
(48) 2.5GbE, 802.3at PoE+ RJ45 ports
(4) 10G SFP+ ports
(1) USP RPS DC input
720W total PoE supply
Layer 3 switching features
Mechanical
Dimensions 442 x 44 x 400 mm (17.4 x 1.7 x 15.7")
Weight Without Mount: 6.2 kg (13.67 lb)
With Mount: 6.3 kg (13.89 lb)
Enclosure Material SGCC Steel
Mount Material SGCC Steel
Hardware
Total Non-Blocking Throughput 160 Gbps
Switching Capacity 320 Gbps
Forwarding Rate 238.095 Mpps
Max Power Consumption (Excluding PoE Output) 150W
Power Method (1) Universal AC input, 100-240VAC, 10A Max, 50/60 Hz
(1) USP-RPS DC input, 52VDC, 13.84A; 11.5VDC, 13A
Power Supply AC/DC, Internal, 100-240V, 10A Max.
Management Interface Ethernet In-Band
Networking Interfaces (48) 100MbE/1GbE/2.5GbE RJ45 port
SFP+ Interfaces (4) 1/10G SFP+ ports
PoE Interfaces (48) PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
Total Available PoE 720W
Max. PoE+ Wattage per Port by PSE 34.2W
Voltage Range 802.3af Mode 44 to 57V
Voltage Range 802.3at Mode 50 to 57V
Services SMB Layer 3 PoE Gigabit Ethernet Switch
ESD/EMP Protection Air: ± 16 kV, Contact: ± 12 kV
Downloads
Datasheet
Installation Guide
