Description
The Hikvision DS‑2CD3786G2HT‑LIZSUY is a premium 8MP Smart Dual‑Light motorized varifocal dome camerafrom the Ultra / SmartIP series. Designed for both residential and business surveillance, it delivers exceptional clarity, low-light performance, and AI capabilities.
- Captures 4K resolution video with a motorized 2.7–13.5 mm varifocal lens, allowing flexible field-of-view adjustment
- Uses Smart Dual‑Light (IR + white light) to ensure clear colour imaging in darkness
- Equipped with DarkFighter‑S technology for enhanced low-light sensitivity
-
Runs on HEOP (Hikvision Embedded Open Platform) with 1.5 TOPS computing power, 40 MB system memory, 350 MB smart RAM, and 2 GB eMMC storage to support onboard AI and third‑party apps
- 130 dB WDR ensures clear imaging even in high-contrast lighting conditions
-
Robustly built: IP67 weatherproof and IK10 vandal-resistant housing
This camera is ideal for users who demand high detail, intelligent imaging, low-light colour performance, and flexibility via motorized focus — in both home and commercial installations.
Key Features
- 8 MP (3840 × 2160) resolution
- Motorized varifocal lens: 2.7–13.5 mm
- Smart Dual‑Light (IR + white) up to ~40 m
- DarkFighter‑S low-light technology
- HEOP with 1.5 TOPS AI, open platform support
- 130 dB WDR
- ONVIF & third‑party app compatibility
- IP67 & IK10 rated
- Adjustable pan (0–355°), tilt (0–75°), rotate (0–355°)
- 1/1.8″ progressive-scan CMOS sensor
- Minimum illumination: 0.0028 lux (colour) / 0 lux (with light)
- Video encoding: H.265+, H.265, H.264+, H.264
Technical Specifications
| DS‑2CD3786G2HT‑LIZSUY Specifications |
| Image Sensor |
1/1.8″ Progressive-Scan CMOS |
| Max Resolution / Frame Rate |
3840 × 2160 @ 25/24 fps |
| Lens (Motorized Varifocal) |
2.7 – 13.5 mm |
| Field of View (H / V / D) |
112.3° – 41.2° / 58.1° – 23.1° / 137.4° – 47.3° |
| Minimum Illumination |
0.0028 lux (colour) / 0 lux (with light) |
| Supplement Light Type |
Smart Dual-Light (IR + White Light) |
| Smart / AI Platform |
HEOP, 1.5 TOPS, open SDK supported |
| Wide Dynamic Range (WDR) |
130 dB |
| Weather / Vandal Protection |
IP67, IK10 |
| Pan / Tilt / Rotate Range |
Pan: 0°–355°, Tilt: 0°–75°, Rotate: 0°–355° |
| Video Compression |
H.265+, H.265, H.264+, H.264 |
| Dimensions / Weight |
(Refer to datasheet) / (Refer to datasheet) |
