Description
Dahua 5MP TiOC 1.0 Active Deterrence IP Bullet Fixed 2.8mm, Built-in Speaker, WDR, Micro SD, IP67, PoE
The Dahua 5MP TiOC 1.0 Active Deterrence IP Bullet Fixed 2.8mm Camera delivers high-quality, low illuminance images with a 5MP image sensor and 1/2.7'' CMOS. It supports up to 5MP resolution @20 fps and uses H.265 codec for efficient compression. With built-in features like WDR, intelligent detection, and IP67 rating, this camera is versatile for any monitoring situation.
Features
- 5MP, 1/2.7'' CMOS image sensor, low illuminance, high image definition
- Outputs max. 5MP (2592x1944) @20 fps, and supports 4MP (2688x1520) @25/30 fps
- H.265 codec, high compression rate, low bit rate
- Built-in warm illuminator, and the max. illumination distance: 40 m
- ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
- Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)
- Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
- Supports sound and light alarm linkage. When an alarm is triggered, the camera links sound alarm and light flashing.
- Supports one-tap disarming. You can disarm the events of alarm output, sending email, audio, and light in the configured period.
- Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and speaker
- 12V DC/PoE power supply
- IP67 protection
- SMD Plus
- Red and blue flashlight alarm
Specifications
| Megapixels |
5 megapixel |
| Camera Style |
Bullet |
| Colour |
White |
| Lens Type |
Fixed |
| Technology |
WizSense Series |
| Connection |
PoE |
Downloads
DH-IPC-HFW3549TP-AS-PV-0280B Datasheet
Bullet Network Camera Installation Guide_V1.0.0
Dahua Bullet Network Camera_QSG_V1.0.2
Dahua Network Camera Web 3.0 Operation Manual_V2.1.1
About Dahua TiOC 2.0, the ultimate 3-in-1 Camera &
Active Deterrent Setup on Dahua's DMSS mobile app
Dahua TiOC cameras offer features like red and blue lights, a siren, and voice messages to simulate a police presence and startle potential intruders. These features can be tailored to specific needs, allowing for customization such as enabling or disabling lights and sirens, and changing voice messages. This technology enhances security by deterring criminals and adding an extra layer of protection. It can complement other security measures like fencing, lighting, and alarms to create a comprehensive security system for both residential and business spaces.
